How Does libfuse Work Under the Hood? A Software Engineer's Code Walkthrough

Every FUSE filesystem you have ever used — sshfs mounting a remote server, s3fs browsing an S3 bucket, mergerfs pooling disks, GVfs exposing GNOME mounts — is just a userspace program talking to /dev/fuse through one library. That library is libfuse, the reference implementation of the FUSE (Filesystem in Userspace) protocol. It has shipped in every major Linux distribution for over two decades, accumulated roughly 6.1 thousand GitHub stars and 270+ contributors (libfuse GitHub), and yet its internals are rarely explained from the code.

The problem is that libfuse is dense. The repository spans roughly 2.5 MB of C across lib/, include/, example/, util/, test/, and doc/. It offers two distinct APIs — a high-level synchronous API and a low-level asynchronous API — that confuse newcomers. The kernel↔userspace protocol is documented in doc/kernel.txt but never tied back to the dispatch code. And the newest major feature, fuse-over-io-uring, landed in 3.18.0 (December 2025) with almost no public walkthrough.

This article fixes that. We will walk through the source top-down: what libfuse is, how the two APIs differ, the request dispatch pipeline, the session lifecycle, the io_uring transport, the example files, and a reading map for newcomers. By the end you will understand the library well enough to read fuse_lowlevel.c — the 144 KB core — and know exactly what each function does.

Key Takeaways

• libfuse provides two APIs: the high-level API (fuse.c, path-based, synchronous callbacks) and the low-level API (fuse_lowlevel.c, inode-based, explicit fuse_reply_*() calls). The high-level API is a thin wrapper over the low-level one.
• Every FUSE operation follows one pipeline: kernel → /dev/fuse → fuse_session_receive() → opcode-indexed dispatch table → your callback → fuse_reply_*() → kernel. The dispatch table fuse_ll_ops[] is the single most important data structure in the library.
• fuse-over-io-uring (3.18.0, December 2025) replaces read/write on /dev/fuse with io_uring queues — one per CPU core — reducing syscall overhead. Enable it with -o io_uring after setting echo 1 > /sys/module/fuse/parameters/enable_uring (libfuse README.fuse-io-uring).
• The project is in limited-maintenance mode: no active regular contributors beyond the maintainer, who applies PRs and ships releases but has no capacity for feature development (libfuse README.md).
• fusermount3 is installed setuid root and enforces mountpoint ownership rules; an unresolved kernel permission-caching bug (known since 2006, issue #15) affects allow_other setups.

What libfuse Is (and Isn't)

FUSE is a split design. The kernel side — the fuse kernel module — lives in the mainline Linux tree (merged in kernel 2.6.14, 2005). It intercepts VFS calls for FUSE-mounted filesystems and forwards them to userspace via the /dev/fuse character device. The userspace side — libfuse, this repository — is the reference library that handles mounting, reading requests from /dev/fuse, dispatching them to your callbacks, and writing responses back.

libfuse does not implement a filesystem. It implements the protocol — the marshalling, the capability negotiation, the session lifecycle, the reply mechanics. Your filesystem (sshfs, mergerfs, your own) links against libfuse and fills in the callbacks.

The library offers two APIs that serve the same protocol but at different abstraction levels:

HIGH-LEVEL API (fuse.c, ~122 KB)        LOW-LEVEL API (fuse_lowlevel.c, ~144 KB)
──────────────────────────────────       ──────────────────────────────────────────
  Callbacks receive path strings           Callbacks receive inode numbers (fuse_ino_t)
       │                                        │
       ▼                                        ▼
  libfuse resolves inode via                You control the inode→object mapping
  internal hash table (node_table)         (no hidden lookups, no hidden cache)
       │                                        │
       ▼                                        ▼
  Callback is SYNCHRONOUS:                  Callback is ASYNCHRONOUS:
  returning from the callback               you MUST call fuse_reply_*()
  automatically sends the reply             explicitly to send the reply
       │                                        │
       ▼                                        ▼
  libfuse handles inode caching,            You control caching via
  attribute caching, directory entry        fuse_reply_entry() with cache TTL,
  cache TTLs internally                     fuse_lowlevel_notify_inval_*()
       │                                        │
       ▼                                        ▼
  Entry point: fuse_main()                  Entry point: fuse_session_new()
  (~50 lines of boilerplate)                → fuse_session_mount()
                                            → fuse_session_loop[_mt]()
                                            → fuse_session_unmount()
                                            → fuse_session_destroy()
       │                                        │
       ▼                                        ▼
  Best for: simple filesystems,             Best for: production filesystems,
  prototypes, sshfs, archivemount           mergerfs, s3fs, gvfs, high-performance FS

The high-level API is literally implemented on top of the low-level API. fuse.c maintains a hash table mapping inode numbers to path strings, translates path-based callbacks into inode-based ones, and calls the low-level reply functions internally. When you call fuse_main(), it creates a session, mounts, runs the loop, and tears down — all the low-level steps, wrapped in one function.

Citation capsule: libfuse is the reference implementation of the FUSE protocol, shipped by all major Linux distributions and in production use for over two decades. It provides both a high-level synchronous API (path-based, fuse_main()) and a low-level asynchronous API (inode-based, fuse_session_new()), with the high-level API implemented as a wrapper over the low-level one (libfuse README.md, 2025).

The Two Public API Headers

Before diving into the implementation, know the two headers you will include:

• include/fuse.h (51 KB) — the high-level API. Defines struct fuse_operations (your callback table with getattr, read, write, readdir, open, init, destroy, etc.), fuse_main(), struct fuse_args, FUSE_ARGS_INIT(), and the option-parsing machinery.
• include/fuse_lowlevel.h (84 KB) — the low-level API. Defines struct fuse_lowlevel_ops (inode-based callbacks: lookup, forget, getattr, read, write, etc.), all fuse_reply_*() functions, the notification API (fuse_lowlevel_notify_inval_inode, fuse_lowlevel_notify_inval_entry, fuse_lowlevel_notify_store, fuse_lowlevel_notify_retrieve), and struct fuse_session.

Both pull in include/fuse_common.h (39 KB) for shared types — struct fuse_file_info, struct fuse_conn_info, the 34+ capability flags (FUSE_CAP_ASYNC_READ, FUSE_CAP_WRITEBACK_CACHE, FUSE_CAP_PASSTHROUGH, FUSE_CAP_OVER_IO_URING), and struct fuse_args. And include/fuse_kernel.h (32 KB) defines the wire protocol structures: struct fuse_in_header, struct fuse_out_header, and all 53 opcodes from FUSE_LOOKUP (1) to FUSE_STATX (52).

The Request Dispatch Pipeline

This is the heart of the library. Every filesystem operation — a read(), a write(), a stat(), an ls — follows the same path through the kernel, the /dev/fuse device, and libfuse into your callback. Here is the flow for a single write() call, traced through the actual source:

┌──────────────┐     ┌───────────────┐     ┌──────────────────────┐     ┌───────────────────┐     ┌─────────────────┐
│  Application │     │  Linux Kernel │     │   libfuse core       │     │  fuse_lowlevel.c  │     │  Your Callback   │
│  write()     │     │  FUSE module  │     │  (session loop)      │     │  (dispatch)       │     │  (filesystem)    │
└──────┬───────┘     └───────┬───────┘     └──────────┬───────────┘     └────────┬──────────┘     └────────┬────────┘
       │                     │                        │                          │                          │
       │  write(fd, buf, n)  │                        │                          │                          │
       ├────────────────────►│  VFS → fuse_request_send()                         │                          │
       │                     │  enqueue on fc->pending │                          │                          │
       │                     │  ──────────────────────►│  fuse_session_receive()  │                          │
       │                     │                        │  read()/splice() from     │                          │
       │                     │                        │  /dev/fuse                │                          │
       │                     │                        ├─────────────────────────►│  fuse_session_process_buf()│
       │                     │                        │                          │  validate header           │
       │                     │                        │                          │  fuse_ll_alloc_req()       │
       │                     │                        │                          │  fuse_req_parse_extensions │
       │                     │                        │                          │  ── dispatch by opcode ──►│
       │                     │                        │                          │  fuse_ll_ops[FUSE_WRITE]   │
       │                     │                        │                          │  .func(req, nodeid, inarg) ├─► .write()
       │                     │                        │                          │                          │  (do your I/O)
       │                     │                        │                          │  fuse_reply_write() ◄──────┤
       │                     │  ◄─────────────────────┼──────────────────────────┼──────────────────────────┤
       │                     │  response via writev() │  fuse_send_msg()         │  send_reply()             │
       │  return bytes       │  to /dev/fuse          │                          │                          │
       ◄─────────────────────┤                        │                          │                          │

Let me walk through each stage in the source.

Stage 1: The Event Loop

The single-threaded loop lives in lib/fuse_loop.c — just 49 lines:

// lib/fuse_loop.c (simplified)
while (!fuse_session_exited(se)) {
    res = fuse_session_receive_buf_internal(se, &fbuf, NULL);
    if (res == -EINTR) continue;
    if (res <= 0) break;
    fuse_session_process_buf(se, &fbuf);
}
if (se->uring.pool) fuse_uring_stop(se);

That is the entire loop: read a buffer, process it, repeat. The multi-threaded variant (lib/fuse_loop_mt.c, 14 KB) wraps this in a dynamic thread pool — worker threads each call fuse_session_receive_buf_internal() under PTHREAD_CANCEL_DISABLE, and the pool grows when numavail == 0 and shrinks idle threads past max_idle.

Stage 2: Receiving the Request

_fuse_session_receive_buf() (in fuse_lowlevel.c, line ~4332) tries splice first — a zero-copy move from /dev/fuse into a pipe, avoiding a copy into userspace memory. This works when FUSE_CAP_SPLICE_READ is negotiated and the protocol minor version is ≥ 14. If splice is unavailable, it falls back to a plain read() on the /dev/fuse file descriptor. The buffer size (se->bufsize) is atomic — the kernel can request a larger buffer during FUSE_INIT, and the receive path detects EINVAL from an undersized buffer, reallocates, and retries.

Stage 3: Processing and Dispatch

fuse_session_process_buf_internal() (line ~4000) does the real work:

1. If the buffer came via splice (FUSE_BUF_IS_FD), copy the header from the pipe into memory.
2. Fire a USDT tracepoint (trace_request_process) for observability.
3. Allocate a request object: fuse_ll_alloc_req(se).
4. Populate the request from the header: fuse_session_in2req(req, in).
5. Parse security-context extensions: fuse_req_parse_extensions() — extracts SELinux/LSM context into req->secctx.
6. Sanity-check the opcode: fuse_req_opcode_sanity_ok() and fuse_req_check_allow_root().
7. Handle interrupts: add to se->list, check for pending FUSE_INTERRUPT requests.
8. Dispatch: fuse_ll_ops[in->opcode].func(req, in->nodeid, inarg).

Stage 4: The Dispatch Table

The dispatch table is the single most important data structure in libfuse. It lives at line 3686 of fuse_lowlevel.c:

static struct {
    void (*func)(fuse_req_t, const fuse_ino_t, const void *);
    const char *name;
} fuse_ll_ops[] = {
    [FUSE_LOOKUP]     = { do_lookup,     "LOOKUP" },
    [FUSE_FORGET]     = { do_forget,     "FORGET" },
    [FUSE_GETATTR]    = { do_getattr,    "GETATTR" },
    [FUSE_SETATTR]    = { do_setattr,    "SETATTR" },
    [FUSE_READLINK]   = { do_readlink,   "READLINK" },
    [FUSE_SYMLINK]    = { do_symlink,    "SYMLINK" },
    [FUSE_MKNOD]      = { do_mknod,      "MKNOD" },
    [FUSE_MKDIR]      = { do_mkdir,      "MKDIR" },
    [FUSE_UNLINK]     = { do_unlink,     "UNLINK" },
    [FUSE_RMDIR]      = { do_rmdir,      "RMDIR" },
    [FUSE_RENAME]     = { do_rename,     "RENAME" },
    [FUSE_LINK]       = { do_link,       "LINK" },
    [FUSE_OPEN]       = { do_open,       "OPEN" },
    [FUSE_READ]       = { do_read,       "READ" },
    [FUSE_WRITE]      = { do_write,      "WRITE" },
    [FUSE_STATFS]     = { do_statfs,     "STATFS" },
    [FUSE_RELEASE]    = { do_release,    "RELEASE" },
    [FUSE_FSYNC]      = { do_fsync,      "FSYNC" },
    // ... all 38 opcodes through FUSE_SYNCFS, FUSE_STATX, CUSE_INIT
};
#define FUSE_MAXOP (CUSE_INIT + 1)

Each do_* function is an internal handler that unpacks the opcode-specific arguments from the generic inarg pointer, calls your callback (stored in se->op), and sends the appropriate reply. For example, do_write() extracts the offset, size, and file handle, calls se->op.write(), then calls fuse_reply_write(req, bytes_written).

There is a parallel table — fuse_ll_ops2[] (line 3743) — with _do_* variants that take an extra op_payload pointer. This exists because in the io_uring transport, the payload arrives separately from the header (in the ring buffer), not appended to it. Both tables must be kept in sync.

Stage 5: The Reply Path

When your callback finishes, you call a fuse_reply_*() function. The generic path:

fuse_reply_write(req, bytes)
  → send_reply(req, bytes, NULL, 0)
    → fuse_send_reply_iov_novree()
      → fuse_send_msg()
        → if req->flags.is_uring: fuse_send_msg_uring()
          else: fuse_write_msg_dev()  → writev() to /dev/fuse fd
  → fuse_free_req(req)   → decrement ref count, destroy when zero

The reply writes a struct fuse_out_header (with error = 0 and unique matching the request) followed by the payload, back to /dev/fuse. The kernel's fuse_dev_write() wakes up the waiting VFS call, and the application's write() returns.

Session and Channel Lifecycle

A struct fuse_session (defined in lib/fuse_i.h) is the central object — it represents one mounted filesystem, one /dev/fuse file descriptor, one set of callbacks. Here is the lifecycle:

fuse_session_new(args, ops, op_size, userdata)
  → parse options, allocate session, copy callback table into se->op
  → se->fd = -1 (not yet mounted)

fuse_set_signal_handlers(se)
  → install handlers for SIGINT/SIGTERM/SIGHUP → fuse_session_exit()

fuse_session_mount(se, mountpoint)
  → fuse_session_mount_new_api()  [preferred: fsopen/fsconfig/fsmount/move_mount]
     OR fuse_kern_mount()         [fallback: mount(2) syscall]
  → opens /dev/fuse, sets se->fd
  → kernel sends FUSE_INIT request (opcode 1)
  → session negotiates protocol version + capabilities

fuse_session_loop[_mt](se)
  → [see dispatch pipeline above]
  → runs until fuse_session_exited(se) is true

fuse_session_unmount(se)
  → close(se->fd), kernel sends FUSE_DESTROY

fuse_remove_signal_handlers(se)
fuse_session_destroy(se)
  → calls se->op.destroy(userdata)
  → frees all pending requests, closes fds, frees session

The mount step deserves attention. libfuse 3.x prefers the new Linux mount API (fsopen()/fsconfig()/fsmount()/move_mount()) introduced in Linux 5.2, falling back to the legacy mount(2) syscall when the new API is unavailable (e.g., older kernels or libc without the wrappers — glibc added them in 2.36). The code lives in lib/mount_fsmount.c (16 KB) and lib/mount.c (22 KB).

The FUSE_INIT handshake is critical. The kernel sends an FUSE_INIT request with its supported protocol version and capability flags. libfuse responds with the intersection — the capabilities both sides support. This is where FUSE_CAP_OVER_IO_URING, FUSE_CAP_WRITEBACK_CACHE, FUSE_CAP_PASSTHROUGH, and the other 30+ flags get negotiated. If the kernel's major version does not match libfuse's, the session refuses to start (the loop exits with -EPROTO).

A synchronous FUSE_INIT mechanism (line 4787) handles a subtle problem: SELinux may send getattr requests before fuse_session_mount() returns. A worker thread (session_sync_init_worker) polls se->fd plus an eventfd, processing requests until the mount handshake completes. Enabled via ioctl(fd, FUSE_DEV_IOC_SYNC_INIT).

A timeout watchdog thread (fuse_session_teardown_watchdog, line 5376) polls the session fd for POLLERR — if the kernel-side connection drops (e.g., the filesystem is killed), the watchdog calls fuse_session_exit() and optionally forces a hard-exit after a configurable timeout.

The io_uring Integration (libfuse 3.18.0+)

The newest major feature in libfuse is fuse-over-io_uring, added in version 3.18.0 (December 18, 2025). It replaces the traditional read()/write() on /dev/fuse with io_uring — a shared ring buffer between kernel and userspace that batches and reduces system calls.

Why It Matters

The classic FUSE path has syscall overhead on every operation: the kernel writes a request to /dev/fuse, the userspace daemon read()s it, processes it, write()s the response. That is two syscalls per operation (one read, one write), plus the context switches. For I/O-heavy workloads, this overhead is significant. io_uring lets both sides operate on a shared ring buffer — the kernel places completion queue entries (CQEs), libfuse processes them in batches, and replies go back through the same ring. Fewer syscalls, less context switching, better throughput.

How It Works in the Code

The implementation lives in lib/fuse_uring.c (26 KB, 1043 lines). The architecture:

CLASSIC TRANSPORT                    IO_URING TRANSPORT
─────────────────                    ──────────────────
  read() / write() on /dev/fuse      io_uring shared ring buffer
  one fd, one thread reads it        one queue per CPU core
  each request = 1 read() syscalls   batch: io_uring_submit_and_wait()
  each reply = 1 write() syscall     reply: FUSE_IO_URING_CMD_COMMIT_AND_FETCH
       │                                  │
       ▼                                  ▼
  fuse_session_receive_buf()         fuse_uring_thread() per queue
  fuse_session_process_buf()         io_uring_wait_cqe() → handle CQE
  fuse_send_msg() → writev()         fuse_ll_ops2[] dispatch (separate payload)
                                     send_reply_uring() → commit SQE

Key structures:

struct fuse_ring_pool {
    struct fuse_session *se;
    bool single_issuer;          // optimization: one thread submits
    size_t nr_queues;            // = get_nprocs_conf() (one per core)
    size_t queue_depth;          // default 8, configurable via -o io_uring_q_depth
    struct fuse_ring_queue *queues;
};

struct fuse_ring_queue {
    int qid;
    pthread_t tid;
    struct io_uring ring;        // the actual io_uring instance
    pthread_mutex_t ring_lock;
    struct fuse_ring_ent ent[];  // flexible array, size = queue_depth
};

The lifecycle:

1. fuse_uring_start(se) — called from do_init after FUSE_INIT negotiation succeeds and FUSE_CAP_OVER_IO_URING is set.
2. fuse_create_ring(se) — allocates the pool with nr_queues = CPU count.
3. fuse_uring_start_ring_threads() — spawns one fuse_uring_thread() per queue.
4. Each thread: sets CPU affinity (fuse_uring_set_thread_core), initializes the io_uring with IORING_SETUP_SQE128 (80-byte cmd data for fuse_uring_cmd_req), registers files, mmaps header/payload buffers, prepares registration SQEs.
5. After FUSE_INIT reply: fuse_uring_wake_ring_threads() posts to init_sem.
6. Main loop: io_uring_submit_and_wait() (single-issuer mode) or io_uring_wait_cqe() (multi-issuer) → fuse_uring_queue_handle_cqes() → fuse_uring_handle_cqe() → fuse_session_process_uring_cqe().

CQE handling extracts the fuse_in_header from the ring's req_header, sets req->flags.is_uring = 1, and dispatches through fuse_ll_ops2[] (the parallel table with separate payload pointers). Replies go through send_reply_uring() which copies the payload into the ring buffer and submits a FUSE_IO_URING_CMD_COMMIT_AND_FETCH SQE.

Notable engineering decisions:

• IORING_SETUP_SQE128 is required (not the default 64-byte SQE) because fuse_uring_cmd_req needs 80 bytes of cmd data (qid, commit_id, flags).
• IORING_SETUP_CQSIZE with cq_entries = depth * 2 prevents CQ overflow.
• IORING_SETUP_SUBMIT_ALL ensures one failing SQE does not stall the batch.
• cqe_processing atomic flag gates io_uring_submit() during CQE handling, allowing batched inline replies.
• alloc_local() uses mmap + SYS_mbind(MPOL_LOCAL) + MADV_POPULATE_WRITE for NUMA-local, prefaulted memory.
• Teardown is signaled via an eventfd poll SQE.

Enabling It

# 1. Enable kernel-side FUSE io_uring (requires Linux 6.x with FUSE io_uring support)
echo 1 > /sys/module/fuse/parameters/enable_uring

# 2. Mount with the io_uring option
./my_fuse_fs /source /mountpoint -o io_uring

# 3. Optionally adjust queue depth (default 8)
./my_fuse_fs /source /mountpoint -o io_uring -o io_uring_q_depth=16

Build libfuse with -Denable-io-uring=true (requires liburing with IORING_SETUP_SQE128 support). The kernel-side protocol capability FUSE_OVER_IO_URING was added in protocol version 7.42.

Citation capsule: fuse-over-io-uring (libfuse 3.18.0, December 2025) replaces read/write on /dev/fuse with io_uring queues — one per CPU core, default depth 8 — reducing syscall overhead. It requires kernel support (echo 1 > /sys/module/fuse/parameters/enable_uring), the FUSE_CAP_OVER_IO_URING capability (protocol 7.42), and the -o io_uring mount option (libfuse README.fuse-io-uring).

The Example Files: Your Entry Point

The example/ directory contains 25+ programs. Three matter most for learning:

example/hello.c — High-Level "Hello World" (4.5 KB)

The canonical starting point. Defines a filesystem with one file (/hello) containing "Hello World!\n". Uses fuse_main() — the entire mount loop is one function call:

static const struct fuse_operations hello_oper = {
    .init     = hello_init,
    .getattr  = hello_getattr,
    .readdir  = hello_readdir,
    .open     = hello_open,
    .read     = hello_read,
};

int main(int argc, char *argv[]) {
    struct fuse_args args = FUSE_ARGS_INIT(argc, argv);
    fuse_opt_parse(&args, &options, option_spec, NULL);
    return fuse_main(args.argc, args.argv, &hello_oper, NULL);
}

Compile: gcc -Wall hello.c $(pkg-config fuse3 --cflags --libs) -o hello

example/hello_ll.c — Low-Level "Hello World" (7 KB)

The same filesystem using the low-level API. This is where you see the inode-based callbacks explicitly:

#define FUSE_USE_VERSION FUSE_MAKE_VERSION(3, 12)
#include <fuse_lowlevel.h>

static const struct fuse_lowlevel_ops hello_ll_oper = {
    .init       = hello_ll_init,
    .lookup     = hello_ll_lookup,
    .getattr    = hello_ll_getattr,
    .readdir    = hello_ll_readdir,
    .open       = hello_ll_open,
    .read       = hello_ll_read,
    // ...
};

int main(int argc, char *argv[]) {
    struct fuse_session *se = fuse_session_new(&args, &hello_ll_oper, sizeof(hello_ll_oper), NULL);
    fuse_set_signal_handlers(se);
    fuse_session_mount(se, opts.mountpoint);
    fuse_session_loop_mt(se, &config);   // or fuse_session_loop() for single-thread
    fuse_session_unmount(se);
    fuse_remove_signal_handlers(se);
    fuse_session_destroy(se);
}

This is the better starting point for understanding the library, because every step is explicit.

example/passthrough_fh.c — Realistic Passthrough (14 KB)

Mirrors an existing directory tree under the mountpoint. Uses the low-level API with file handles (FUSE_CAP_EXPORT_SUPPORT + fh field in fuse_file_info). This is the template most real filesystems start from. The C++ variant passthrough_hp.cc (49 KB) adds writeback caching and io_uring support — the most complete example in the repository.

How to Read the Source: A Map for Newcomers

If you want to understand libfuse from the code, read in this order:

1. include/fuse_lowlevel.h (84 KB) — the public structs and callback signatures. Start with struct fuse_lowlevel_ops (your callback table), struct fuse_file_info, struct fuse_conn_info, and the fuse_reply_*() function declarations. This is the contract between you and the library.

2. example/hello_ll.c (7 KB) — a working low-level filesystem in ~200 lines. Read it alongside the header to see how the callbacks are wired up.

3. lib/fuse_lowlevel.c (144 KB) — the core. Focus on:

   • fuse_session_new() — session creation and option parsing
   • fuse_session_mount() — the mount handshake
   • fuse_ll_ops[] (line 3686) — the dispatch table
   • fuse_session_process_buf_internal() (line ~4000) — request processing
   • do_write(), do_read() — representative opcode handlers
   • send_reply() → fuse_send_msg() — the reply path
   • fuse_session_loop() — the event loop entry

4. lib/fuse_session.c — session lifecycle: mount, unmount, signal handling, the sync-init worker, the timeout watchdog.

5. lib/fuse.c (122 KB) — the high-level wrapper. Focus on how fuse_main() calls into the low-level API, and how the node_table hash maps inodes to paths.

6. lib/fuse_uring.c (26 KB) — the io_uring transport. Read after you understand the classic path.

7. doc/kernel.txt (15 KB) — the kernel protocol reference: the /dev/fuse interface, the /sys/fs/fuse/connections control filesystem, interrupt semantics, non-privileged mount security model.

8. doc/fuse-operations.txt (13 KB) — the FUSE protocol operations reference.

The Test Suite

libfuse ships a custom-built test infrastructure — no external framework. test/run-tests.py (71 KB) discovers test/cases/**/*.sh, runs each in its own cgroup with a private work directory, enforces # TIMEOUT: directives, collects core dumps and backtraces, and reports PASS/SKIP/FAIL.

The test/cases/ directory holds 80+ shell scripts across:

• examples/ (38 scripts) — test each example filesystem (hello, passthrough, cuse, poll, notify_*)
• notify/ (16 scripts) — test notification mechanisms
• mount/ (24 scripts) — test mount options and attributes
• unit/ — C unit tests (ABI compatibility, loop config, mount flags)
• ctests/ — shell tests for signals, teardown-watchdog, write-cache

Tests run over both transports: meson test (classic) and meson test --suite io-uring. The runner scans output for suspicious patterns (error/warning/fatal/crash/abort/exception) and supports Valgrind (TEST_WITH_VALGRIND=1).

Notable: tests can require root, but most run as a regular user if util/fusermount3 is made setuid root first — the rest skip themselves gracefully.

fusermount3: The setuid Helper

util/fusermount.c (45 KB) implements fusermount3, installed setuid root so unprivileged users can mount filesystems. It opens /dev/fuse, performs the privileged mount operation, then passes the file descriptor back to the daemon via the _FUSE_COMMFD environment variable.

Security restrictions enforced by fusermount3:

• The user can only mount on a mountpoint where they have write permission
• The mountpoint must not be a sticky directory not owned by the user (like /tmp)
• No other user (including root) can access the mounted filesystem unless allow_other/allow_root is configured in /etc/fuse.conf

The auto_unmount option holds the commfd open — when the daemon exits (even crashes), the kernel automatically unmounts. drop_privileges opens /dev/fuse before setuiding down, so the mount fd is owned by the target user.

A known unresolved kernel bug (issue #15, documented since 2006): when allow_other is used without default_permissions, the first permission check result for a directory entry is cached and reused for subsequent accesses as long as the inode stays in the kernel cache — even if permissions change, even for different users. The workaround is default_permissions (which does not support ACLs) or disabling directory entry attribute caching.

Project Status and History

libfuse has been in production since 2001. The original author, Miklos Szeredi (who also maintains the kernel FUSE subsystem), handed off maintenance in 2015. Nikolaus Rath maintained it until February 2024. The current maintainers — Bernd Schubert, Ashley Pittman, and Antonio SJ Musumeci (creator of mergerfs) — apply PRs and ship releases but have no capacity for feature development.

The README is unusually honest: "at present libfuse does not have any active, regular contributors... unless you are including a pull request or are reporting a critical issue, you will probably not get a response."

Key milestones from the ChangeLog:

The library is stable, mature, and widely deployed. It is not dead — but it is not growing either. The io_uring work is the most significant architectural change in years.

Frequently Asked Questions

What is the difference between the high-level and low-level libfuse APIs?

The high-level API (fuse.h) uses path strings and synchronous callbacks — returning from the callback automatically sends the reply. The low-level API (fuse_lowlevel.h) uses inode numbers and requires explicit fuse_reply_*() calls, giving you full control over caching, concurrency, and reply timing. The high-level API is implemented as a wrapper over the low-level one. Most production filesystems (mergerfs, s3fs, gvfs) use the low-level API.

Is libfuse still actively maintained?

The README states there are no active regular contributors beyond the current maintainer team, who apply PRs and ship releases but have no capacity for feature development. It is stable and mature — not dead, but do not expect new features beyond high-impact fixes. The latest release is 3.18.2 (March 2025).

Can I use libfuse on macOS?

No. libfuse targets Linux (fully) and BSD (best-effort). On macOS, use macFUSE, which is a separate project with its own kernel extension.

How does FUSE performance compare to a kernel module?

FUSE trades peak performance for safety and development speed. A crash in a FUSE filesystem takes down one process, not the whole kernel. Development is orders of magnitude faster. The performance gap is narrowing: FUSE_WRITEBACK_CACHE (protocol 7.23) enables kernel-side write buffering, FUSE_PASSTHROUGH (protocol 7.40) lets the kernel read/write directly to a backing file, and fuse-over-io-uring (3.18.0) reduces syscall overhead.

What is the FUSE protocol version?

The current protocol is 7.45 (kernel/userspace interface). Capabilities are negotiated at mount time via the FUSE_INIT handshake — both sides advertise supported features and the intersection is used. New capabilities (like FUSE_CAP_OVER_IO_URING at 7.42) are added in minor version bumps.

Conclusion

libfuse is a masterclass in protocol-library design: a clean split between high-level and low-level APIs, a single dispatch table that routes every kernel opcode to a handler, a carefully managed session lifecycle with sync-init and timeout watchdog, and a new io_uring transport that reduces syscall overhead without changing the user-facing API.

The codebase rewards top-down reading. Start with fuse_lowlevel.h and hello_ll.c, then read the dispatch table in fuse_lowlevel.c, then the session lifecycle in fuse_session.c, then the io_uring transport in fuse_uring.c. Build the examples with meson setup build && ninja -C build, mount hello_ll on a test directory, and watch the dispatch pipeline in action with strace -e read,write.

The repository is at github.com/libfuse/libfuse. Clone it, read it, and the next time you sshfs into a remote server or s3fs mount a bucket, you will know exactly what happens between the VFS call and your callback.

Sources

• libfuse README.md, https://github.com/libfuse/libfuse
• libfuse README.fuse-io-uring, https://github.com/libfuse/libfuse/blob/master/doc/README.fuse-io-uring
• libfuse ChangeLog.rst, https://github.com/libfuse/libfuse/blob/master/ChangeLog.rst
• libfuse AUTHORS, https://github.com/libfuse/libfuse/blob/master/AUTHORS
• libfuse doc/kernel.txt (kernel protocol reference), https://github.com/libfuse/libfuse/blob/master/doc/kernel.txt
• libfuse example/hello_ll.c, https://github.com/libfuse/libfuse/blob/master/example/hello_ll.c
• libfuse example/hello.c, https://github.com/libfuse/libfuse/blob/master/example/hello.c
• libfuse include/fuse_kernel.h (wire protocol), https://github.com/libfuse/libfuse/blob/fuse-3.18.0/include/fuse_kernel.h
• Kernel FUSE documentation, https://www.kernel.org/doc/html/next/filesystems/fuse.html
• Wikipedia — Filesystem in Userspace, https://en.wikipedia.org/wiki/Filesystem_in_Userspace
• LWN.net — "A FUSE implementation for famfs", https://lwn.net/Articles/1020170/
• LWN.net — "Famfs, FUSE, and BPF", https://lwn.net/Articles/1068686/
