When Does Linux Actually Run Out of Memory? — The OOM Killer's Real Trigger Conditions

Every Linux developer has seen it: the dreaded "Out of Memory: Killed process" line in dmesg. The assumption is almost always the same — the server ran out of memory, so the kernel killed something. But this explanation hides a far more interesting reality.

The truth is that Linux OOM is not a single event. It is the end of a five-step failure chain, and you can trigger it even when free memory exists. The allocation order matters more than total memory. The kernel's choice of victim follows a surprisingly simple scoring formula. And after selecting a target, the kernel deliberately waits two seconds before pulling the trigger.

This article walks through the OOM killer source in mm/oom_kill.c and mm/page_alloc.c to answer one question: when, exactly, does Linux decide to kill a process?

Key Takeaways

• OOM triggers after 5 progressive allocation failures (fast path → kswapd → direct reclaim → compaction → OOM), not when memory hits 100%. You can OOM with free memory available.
• oom_badness() scores victims by: RSS + swap_usage + page_tables, then normalizes with oom_score_adj × totalpages / 1000. The process with the highest score dies.
• oom_score_adj = -1000 (OOM_SCORE_ADJ_MIN) makes a process unkillable — the kernel returns LONG_MIN for its score.
• OOM Reaper waits exactly 2 seconds (OOM_REAPER_DELAY) before forced reaping, because futex robust lists live in anonymous memory and reaping too early kills waiters before they wake.
• CONSTRAINT modes change OOM behavior: CONSTRAINT_MEMCG kills within a cgroup only, while CONSTRAINT_NONE kills system-wide.

The Myth: "Memory Full = OOM"

The most persistent misconception about Linux OOM is that it happens when memory reaches 100%. In production, the opposite pattern is common: you find an OOM kill in dmesg, check monitoring, and see free memory at the time of death. How?

The answer lies in understanding that OOM is not about how much memory is used — it is about whether the allocator can satisfy a new request. Three scenarios produce OOM with free memory:

1. Fragmentation: Free memory exists but not in contiguous blocks large enough for the requested order
2. GFP_ATOMIC: A high-priority allocation that cannot sleep for reclaim (interrupt context, spinlock held)
3. Cgroup limits: A cgroup hits its memory.max while the host has plenty of free memory

Kubernetes OOMKilled events (exit code 137) are the most common production manifestation. A container with a 4 GB memory limit triggers cgroup OOM even when the host has 64 GB free. The kernel's CONSTRAINT_MEMCG mode restricts the OOM search to processes within that cgroup only.

The key insight: OOM is a forward-looking failure. The kernel triggers it when it determines that reclaim, compaction, and fallback have all been exhausted — not when the last page is consumed.

The Five-Step Allocation Path: Where OOM Really Lives

OOM is reached through a progressive failure chain. Each step is an increasingly expensive attempt to free memory. Only when all five fail does the kernel invoke the OOM killer.

┌─────────────────────────────────────────────────────────────────────────┐
│                     __alloc_pages_noprof()                              │
│                     (mm/page_alloc.c)                                   │
│                                                                         │
│  ┌─────────────────────────────────────────────────────────────────┐   │
│  │ Step 1: FAST PATH — get_page_from_freelist()                   │   │
│  │ • Check Per-CPU pageset (PCP) cache first                     │   │
│  │ • Allocate from zone free_area[order] if available             │   │
│  │ • Latency: ~100ns (no locks in hot path)                      │   │
│  │ • Success rate: ~95% of all allocations                       │   │
│  │                          │                                      │   │
│  │                          ▼ (fail: no pages in PCP/freelist)    │   │
│  │  ┌─────────────────────────────────────────────────────────┐   │   │
│  │  │ Step 2: WAKE KSWAPD                                     │   │   │
│  │  │ • Free pages < pages_high watermark                     │   │   │
│  │  │ • Wake per-NUMA-node kswapd thread                      │   │   │
│  │  │ • Set ALLOC_KSWAPD flag, retry fast path                │   │   │
│  │  │ • Latency: ~1-10ms (context switch to kswapd)           │   │   │
│  │  │ • Background reclaim: does not block allocator          │   │   │
│  │  │                      │                                  │   │   │
│  │  │                      ▼ (fail: kswapd couldn't free enough)│   │   │
│  │  │  ┌─────────────────────────────────────────────────┐   │   │   │
│  │  │  │ Step 3: DIRECT RECLAIM — try_to_free_pages()    │   │   │   │
│  │  │  │ • Synchronous reclaim in allocation context     │   │   │   │
│  │  │  │ • shrink_lruvec() scans LRU lists               │   │   │   │
│  │  │  │ • shrink_active_list() → shrink_inactive_list() │   │   │   │
│  │  │  │ • Latency: 10-100ms (the "allocation stall")    │   │   │   │
│  │  │  │ • Only triggered for __GFP_RECLAIM allocations  │   │   │   │
│  │  │  │                  │                              │   │   │   │
│  │  │  │                  ▼ (fail: all LRU pages pinned)  │   │   │   │
│  │  │  │  ┌─────────────────────────────────────────┐   │   │   │   │
│  │  │  │  │ Step 4: COMPACTION                       │   │   │   │   │
│  │  │  │  │ • try_to_compact_pages()                │   │   │   │   │
│  │  │  │  │ • Only for order ≥ 3 (≥ 8 pages)        │   │   │   │   │
│  │  │  │  │ • Migrates pages to create contig blocks │   │   │   │   │
│  │  │  │  │ • Latency: 50-500ms                     │   │   │   │   │
│  │  │  │  │ • Skipped for GFP_ATOMIC                │   │   │   │   │
│  │  │  │  │              │                          │   │   │   │   │
│  │  │  │  │              ▼ (fail: fragmented memory) │   │   │   │   │
│  │  │  │  │  ┌─────────────────────────────────┐   │   │   │   │   │
│  │  │  │  │  │ Step 5: OOM — __alloc_pages_    │   │   │   │   │   │
│  │  │  │  │  │      may_oom()                  │   │   │   │   │   │
│  │  │  │  │  │ • Only if order ≤ 3 (≤ 8 pages) │   │   │   │   │   │
│  │  │  │  │  │ • Not __GFP_THISNODE            │   │   │   │   │   │
│  │  │  │  │  │ • highest_zoneidx >= ZONE_NORMAL│   │   │   │   │   │
│  │  │  │  │  │ • Calls out_of_memory()         │   │   │   │   │   │
│  │  │  │  │  └─────────────────────────────────┘   │   │   │   │   │
│  │  │  │  └─────────────────────────────────────────┘   │   │   │   │
│  │  │  └─────────────────────────────────────────────────┘   │   │   │
│  │  └─────────────────────────────────────────────────────────┘   │   │
│  └─────────────────────────────────────────────────────────────────┘   │
└─────────────────────────────────────────────────────────────────────────┘

Step 1: Fast Path — get_page_from_freelist()

The vast majority of allocations (~95%) succeed here. The allocator checks two sources:

1. Per-CPU Pageset (PCP): Each CPU maintains pcp->high hot/cold page lists for order-0 allocations. These are lockless on the allocating CPU — the fastest path.

2. Zone free lists: The buddy allocator's free_area[order] arrays. If a block of the requested order exists, __rmqueue_smallest() splits larger blocks as needed.

The fast path succeeds when free pages are readily available. It fails when the zone's free memory drops below the pages_min watermark — at which point the allocator escalates to Step 2.

Step 2: Wake kswapd

When free pages fall below pages_high, the allocator wakes the per-NUMA-node kswapd thread. This is background reclaim — kswapd runs asynchronously and does not block the allocating process.

// mm/page_alloc.c — __alloc_pages_slowpath()
if (alloc_flags & ALLOC_KSWAPD)
    wake_all_kswapds(order, gfp_mask, ac);

kswapd's balance_pgdat() loop reclaims pages until free memory rises above pages_high. The allocator sets ALLOC_KSWAPD and retries the fast path. If kswapd frees enough pages, the allocation succeeds and OOM is never reached.

This step fails when kswapd cannot reclaim enough pages — either because all pages are pinned (mlocked), or because the workload is generating dirty pages faster than writeback can flush them.

Step 3: Direct Reclaim — try_to_free_pages()

When background reclaim is insufficient, the allocator performs synchronous reclaim in the allocation context. This is the step that causes visible latency spikes — the allocating process is now blocked, scanning LRU lists, writing back dirty pages, and unmapping shared memory.

The core reclaim loop lives in shrink_lruvec() (mm/vmscan.c:5897):

static void shrink_lruvec(struct lruvec *lruvec, struct scan_control *sc)
{
    get_scan_count(lruvec, sc, nr);
    for_each_evictable_lru(lru) {
        shrink_list(lru, nr_to_scan, lruvec, sc);
    }
}

Each NUMA node maintains 5 LRU lists: INACTIVE_ANON, ACTIVE_ANON, INACTIVE_FILE, ACTIVE_FILE, UNEVICTABLE. Reclaim scans the inactive lists first. Clean file pages are dropped from page cache. Dirty file pages trigger writeback. Anonymous pages are swapped out.

Direct reclaim fails when all pages on the inactive lists are referenced (recently accessed), all dirty pages are already under writeback, and anonymous pages have no swap space.

Step 4: Compaction — try_to_compact_pages()

Compaction is only triggered for high-order allocations (order ≥ 3, meaning ≥ 8 contiguous pages). The buddy allocator needs contiguous physical blocks, but fragmentation over time scatters free pages.

Compaction migrates movable pages to create contiguous blocks:

// mm/compaction.c
compact_zone(struct zone *zone, struct compact_control *cc)
{
    isolate_migratepages(zone, cc);  // Find movable pages
    migrate_pages(&cc->migratepages); // Move them
}

This step is skipped for GFP_ATOMIC allocations (cannot sleep) and for low-order allocations (always satisfiable from PCP).

Compaction fails when movable pages are pinned or when no contiguous block can be formed even after migration.

Step 5: OOM — __alloc_pages_may_oom()

Only reached when all previous steps fail. But even here, OOM is not automatic — the function performs several guards:

// mm/page_alloc.c — __alloc_pages_may_oom()
if (order > PAGE_ALLOC_COSTLY_ORDER)  // order > 3
    return false;  // Don't OOM for large allocations
if (gfp_mask & __GFP_THISNODE)
    return false;  // Node-local allocation, no fallback
if (highest_zoneidx < ZONE_NORMAL)
    return false;  // HighMem zone, skip OOM

If all guards pass, the function calls out_of_memory() — and the OOM killer begins its work.

Decoding oom_badness(): The Kernel's Morbid Calculus

Once out_of_memory() is called, the kernel must choose a victim. The scoring algorithm lives in oom_badness() (mm/oom_kill.c:199) and is surprisingly straightforward:

// mm/oom_kill.c — oom_badness()
long oom_badness(struct task_struct *p, unsigned long totalpages)
{
    long points;

    // Base score: RSS + swap usage + page table overhead
    points = get_mm_rss_sum(p->mm)
           + get_mm_counter_sum(p->mm, MM_SWAPENTS)
           + mm_pgtables_bytes(p->mm) / PAGE_SIZE;

    // Apply oom_score_adj (normalized to totalpages / 1000)
    adj = (long)p->signal->oom_score_adj;
    adj *= totalpages / 1000;
    points += adj;

    // Special cases
    if (p->flags & PF_KTHREAD)      // Kernel threads: unkillable
        return LONG_MIN;
    if (p->signal->oom_score_adj == OOM_SCORE_ADJ_MIN)  // -1000
        return LONG_MIN;
    if (p->signal->oom_score_adj == OOM_SCORE_ADJ_MAX)  // +1000
        return LONG_MAX;

    return points;
}

The Scoring Formula

The score has three components:

Then the adjustment: adj = oom_score_adj × totalpages / 1000

On a 4 GB RAM system (totalpages ≈ 1,048,576):

• oom_score_adj = +500 adds ~524,288 points (equivalent to 2 GB of RSS)
• oom_score_adj = -1000 subtracts ~1,048,576 points (returns LONG_MIN, unkillable)

The oom_score_adj Scale

◄──────────────────────────────────────────────────────────────────────►
-1000                    0                    +1000
  │                      │                      │
  │  UNKILLABLE          │  NORMAL              │  ALWAYS KILL FIRST
  │  returns LONG_MIN    │  no adjustment       │  returns LONG_MAX
  │                      │                      │
  ├─ init (PID 1)        ├─ Most processes      ├─ Nobody sets this
  ├─ systemd             │                      │   intentionally
  ├─ sshd (if set)       │                      │
  └─ database servers    │                      │
     (best practice)     │                      │

Who Gets Killed?

select_bad_process() iterates all tasks via for_each_process(), calling oom_evaluate_task() for each. The task with the highest score wins (and dies).

Practical implications:

• Memory-hungry processes die first — a process using 8 GB RSS scores higher than one using 1 GB
• Kernel threads never die — PF_KTHREAD flag returns LONG_MIN
• Processes dying naturally get priority — oom_task_origin() returns LONG_MAX for tasks with pending SIGKILL
• Init (PID 1) never dies — protected by oom_score_adj = -1000 in modern distributions

The OOM Reaper: Why the Kernel Waits 2 Seconds

After oom_kill_process() sends SIGKILL, the victim doesn't immediately release its memory. The process needs to exit, and exiting takes time. The kernel has two mechanisms:

Immediate: SIGKILL Delivery

oom_kill_process() marks the victim's mm for OOM (MMF_OOM_SKIP) and sends SIGKILL:

// mm/oom_kill.c — oom_kill_process()
mark_oom_victim(victim);
do_send_sig_info(SIGKILL, SEND_SIG_FORCED, victim, true);

But the victim might be in TASK_UNINTERRUPTIBLE state (waiting on I/O), or it might be the init process (unkillable). SIGKILL only works when the process reaches a signal-checkpoint.

Delayed: OOM Reaper

For cases where the victim doesn't exit naturally, the kernel queues an OOM Reaper work item:

// mm/oom_kill.c — queue_oom_reaper()
static void queue_oom_reaper(struct task_struct *victim)
{
    // Wait OOM_REAPER_DELAY (2 seconds) for natural exit
    queue_delayed_work(system_wq, &oom_reaper_work,
                       OOM_REAPER_DELAY);  // HZ * 2 = 2 seconds
}

The 2-second delay (OOM_REAPER_DELAY) exists for a specific reason: futex robust lists. When a process holds a futex, its robust list (a list of futexes to unlock on death) sits in anonymous memory. If the OOM reaper unmaps that memory before the process's futex waiters are woken, those waiters crash on dangling pointers.

After the delay, zap_vma_for_reaping() unmaps all anonymous pages of the victim — freeing memory even if the process itself is stuck.

CONSTRAINT Modes: Not All OOMs Are Equal

The out_of_memory() function determines a constraint that changes which processes are considered:

// mm/oom_kill.c — out_of_memory()
constraint = constrained_alloc(gfp_mask, nid, &nodemask, &cpuset_mems_allowed);

Cgroup OOM: The Container Reality

CONSTRAINT_MEMCG is the mode that triggers Kubernetes OOMKilled events. When a container hits its memory.max:

1. The allocation fails in mem_cgroup_charge()
2. __mem_cgroup_oom() is called instead of out_of_memory()
3. Only processes within that cgroup are scored
4. The host continues running unaffected

This is why a container can be OOMKilled (exit code 137) while the host shows 50% free memory — the constraint limits the scope.

How to Observe OOM in Practice

Tracing OOM with bpftrace

This script traces every entry to the OOM path and logs the victim selection:

#!/usr/bin/env bpftrace
// trace_oom.bt — trace OOM killer entry points

kprobe:__alloc_pages_may_oom
{
    $alloc = (struct alloc_context *)arg1;
    printf("[%s] OOM path entered: order=%d gfp_mask=%x migratetype=%d\n",
           comm, $alloc->order, arg2, $alloc->migratetype);
}

kprobe:oom_kill_process
{
    $victim = (struct task_struct *)arg1;
    printf("[%s] Killing PID %d (%s), score=%d\n",
           comm, $victim->pid, $victim->comm,
           $victim->signal->oom_score);
}

tracepoint:oom:mark_victim
{
    printf("OOM victim marked: PID %d, score %d\n",
           args->pid, args->totalpages);
}

Run with: sudo bpftrace trace_oom.bt

Reading /proc for OOM Insights

# Check current OOM score for a process
cat /proc/<pid>/oom_score        # Dynamic score (0 to ~totalpages)
cat /proc/<pid>/oom_score_adj    # Adjustment (-1000 to +1000)

# Protect a critical process (e.g., database)
echo -1000 > /proc/<pid>/oom_score_adj

# List processes by OOM score (highest = most likely to die)
for pid in $(ls /proc | grep -E '^[0-9]+$'); do
    if [ -f /proc/$pid/oom_score ]; then
        echo "$(cat /proc/$pid/oom_score) $(cat /proc/$pid/comm 2>/dev/null)"
    fi
done | sort -rn | head -10

Reading the Kernel Log

# View OOM events
dmesg | grep -i "out of memory"

# Example output:
# Out of memory: Killed process 12345 (java) total-vm:8388608kB,
# anon-rss:4194304kB, file-rss:0kB, shmem-rss:0kB,
# oom_score_adj:0

# With systemd
journalctl -k | grep -i "oom\|out of memory\|killed process"

Frequently Asked Questions

Can OOM happen even with free memory?

Yes. Three common scenarios: (1) GFP_ATOMIC allocation that cannot sleep for reclaim, (2) memory fragmentation where no contiguous block exists for the requested order, (3) cgroup memory limit reached while host has free memory. The OOM killer triggers when the allocator predicts it cannot satisfy the request — not when the last page is consumed.

How do I protect a critical process from OOM?

Set oom_score_adj = -1000 via echo -1000 > /proc/<pid>/oom_score_adj. This makes oom_badness() return LONG_MIN, rendering the process unkillable. For databases and control-plane services, this is standard practice. You can also use prctl(PR_SET_DUMPABLE) programmatically.

What is the difference between OOM and cgroup OOM?

System OOM (CONSTRAINT_NONE) considers all processes on the host. Cgroup OOM (CONSTRAINT_MEMCG) only considers processes within the cgroup that hit its memory.max limit. A container can be OOMKilled (exit code 137) while the host runs normally — this is the most common Kubernetes production issue.

Why does my server OOM with swap available?

Anonymous pages must be swapped out to reclaim memory. If vm.swappiness = 0 (the default on many distributions since kernel 3.5), the kernel strongly prefers file cache eviction over swapping. When the file cache is small and anonymous pages dominate, no reclaimable pages exist — triggering OOM despite available swap space.

How do I debug an OOM event after it happens?

Check dmesg for the OOM kill message — it includes the victim's PID, command name, total-vm, anon-rss, file-rss, and oom_score_adj. Use bpftrace to trace future OOMs in real-time. Monitor /proc/<pid>/oom_score of critical processes proactively — a rising score indicates increasing OOM risk.

What is pagefault_out_of_memory()?

A separate OOM entry point in mm/memory.c. When a page fault handler returns VM_FAULT_OOM, this function is called. Unlike the alloc path OOM, it can retry because the fault context doesn't hold locks. It is a secondary OOM path that handles page-fault-induced memory exhaustion.

Conclusion

The Linux OOM killer is not a simple "memory full" trigger. It is the endpoint of a five-step allocation failure chain that includes fast-path allocation, background reclaim, synchronous reclaim, compaction, and finally OOM. Understanding this path explains why OOM can happen with free memory, why containers OOM independently of the host, and why oom_score_adj is the most effective tool for protecting critical services.

The kernel's scoring algorithm — RSS plus swap plus page tables, scaled by oom_score_adj × totalpages / 1000 — is deliberately simple. It targets the process consuming the most memory, with a tunable adjustment for operational control. The 2-second OOM Reaper delay is a pragmatic compromise between freeing memory quickly and avoiding corruption of futex robust lists.

For production systems, the key takeaways are: monitor /proc/<pid>/oom_score proactively, set oom_score_adj = -1000 for critical services, understand your cgroup memory constraints, and remember that OOM is about allocation predictions, not current memory consumption.

Sources

• Linux kernel source, mm/oom_kill.c, __alloc_pages_may_oom() and oom_badness(), https://git.kernel.org
• Linux kernel source, mm/page_alloc.c, get_page_from_freelist() and __alloc_pages_slowpath()
• Linux kernel source, mm/vmscan.c, shrink_lruvec() and try_to_free_pages()
• Linux kernel source, mm/compaction.c, try_to_compact_pages()
• Linux kernel Documentation, admin-guide/mm/oom_killer, https://www.kernel.org/doc/html/latest/admin-guide/mm/oom_killer.html
• Kubernetes documentation, OOMKilled and exit code 137, https://kubernetes.io/docs/tasks/configure-pod-container/assign-memory-resource/
