Every developer who has profiled an I/O-bound application has seen the same surprising result: a read() syscall returns in microseconds, even though the disk would take milliseconds to fetch the data. The explanation is the page cache — Linux's in-memory cache of file content that makes most file reads entirely RAM operations.
But the page cache is more than a simple cache. It is a sophisticated system that predicts future access (readahead), delays writes to batch them efficiently (writeback), maintains coherency with the disk (dirty page tracking), and adapts to workload patterns (adaptive readahead). Understanding the page cache explains why write() returns instantly but fsync() can take milliseconds, why sequential reads are 100x faster than random reads, and why Linux uses almost all "free" RAM for caching.
This article walks through the page cache source in mm/filemap.c to explain how filemap_read() serves data from cache, how page_cache_async_ra() predicts sequential access, and how writeback_single_inode() eventually gets data to disk.
Key Takeaways
- Most file reads never touch the disk — the page cache serves data from RAM
filemap_read()uses xarray lookup to find cached pages in O(1)- Readahead predicts sequential access and prefetches pages before they're needed
- Writeback delays disk writes 5-30 seconds to batch them efficiently
- Dirty pages are tracked via
PAGECACHE_TAG_DIRTYfor efficient writeback scanningfsync()forces data to disk — the only way to guarantee durability
The Myth: "read() Reads from Disk"
The mental model: read(fd, buf, 4096) → kernel reads 4096 bytes from disk → copies to buf. This is wrong for the common case.
What actually happens:
read(fd, buf, 4096)
│
▼
┌─────────────────────────────────────────────────────────────────────┐
│ Step 1: filemap_read() │
│ • Look up the page in page cache (xarray) │
│ • Cache HIT: copy data from RAM → return immediately (~1 μs) │
│ • Cache MISS: allocate page → read from disk → copy (~5 ms) │
└─────────────────────────────────────────────────────────────────────┘
│
▼
┌─────────────────────────────────────────────────────────────────────┐
│ Step 2: pagecache_get_page() │
│ • Calculate page index: offset / PAGE_SIZE │
│ • Look up in mapping->i_pages (xarray) │
│ • If found: return the page (mark as accessed) │
│ • If not found: allocate new page, add to xarray, mark for I/O │
└─────────────────────────────────────────────────────────────────────┘
For a warm cache (data already in RAM), the entire operation is a single xarray lookup + memory copy — no disk I/O, no syscall overhead beyond the entry/exit.
The Page Cache Architecture
xarray: The Index Structure
The page cache is indexed by an xarray (extended radix tree) stored in address_space->i_pages:
// include/linux/fs.h
struct address_space {
struct inode *host; // Owning inode
struct xarray i_pages; // Page cache index
struct rw_semaphore invalidate_lock;
gfp_t gfp_mask;
struct rb_root_cached i_mmap; // Tree of memory mappings
unsigned long nrpages; // Number of cached pages
pgoff_t writeback_index; // Writeback starts here
const struct address_space_operations *a_ops;
unsigned long flags; // AS_EIO, AS_ENOSPC, etc.
};The xarray maps (page_offset) → struct page. Lookup is O(1) average case.
pagecache_get_page(): The Lookup Function
// mm/filemap.c — pagecache_get_page()
struct page *pagecache_get_page(struct address_space *mapping,
pgoff_t index, gfp_t gfp)
{
struct page *page;
retry:
// Fast path: lookup in xarray
page = xa_find(&mapping->i_pages, &index, ULONG_MAX, XA_PRESENT);
if (page) {
// Cache hit!
if (PageReclaim(page))
// Page is being reclaimed — wait
wait_on_page_locked(page);
return page;
}
// Cache miss — allocate new page
page = __page_cache_alloc(gfp);
if (!page)
return NULL;
// Insert into xarray
int err = xa_insert(&mapping->i_pages, index, page, gfp);
if (err) {
// Someone else inserted first — use theirs
put_page(page);
goto retry;
}
// Mark for I/O — actual read happens later
return page;
}filemap_read(): The Read Path
// mm/filemap.c — filemap_read()
static ssize_t filemap_read(struct kiocb *iocb, struct iov_iter *to,
ssize_t already_read)
{
struct file *filp = iocb->ki_filp;
struct address_space *mapping = filp->f_mapping;
struct inode *inode = mapping->host;
struct folio *folio;
size_t copied = 0;
// Read pages one at a time
for (;;) {
// Find or create the page
folio = filemap_get_folio(mapping, iocb->ki_pos >> PAGE_SHIFT);
if (!folio) {
// Cache miss — need disk I/O
folio = filemap_create_folio(mapping, iocb->ki_pos >> PAGE_SHIFT);
if (IS_ERR(folio))
break;
// Read from disk
filemap_read_folio(folio);
}
// Copy data from page to user buffer
size_t bytes = copy_folio_to_iter(folio, offset, to);
// Update position
iocb->ki_pos += bytes;
copied += bytes;
// Check if we're done
if (iov_iter_count(to) == 0)
break;
// Trigger readahead for sequential access
page_cache_sync_ra(mapping, folio, iocb->ki_pos >> PAGE_SHIFT);
}
return copied;
}filemap_get_folio(): Cache Lookup
// mm/filemap.c
struct folio *filemap_get_folio(struct address_space *mapping, pgoff_t index)
{
struct folio *folio;
// Fast path: lookup in xarray
folio = xa_load(&mapping->i_pages, index);
if (folio) {
// Cache hit!
folio_accessed(folio); // Mark as accessed for LRU
return folio;
}
// Cache miss
return NULL;
}Readahead: Predicting the Future
The Problem: Disk Latency
A single 4KB random read from an SSD takes ~100 μs. If each read() triggered a disk access, throughput would be limited to ~40 MB/s. Readahead solves this by detecting sequential access patterns and prefetching data before it's requested.
page_cache_sync_ra(): Synchronous Readahead
// mm/filemap.c — page_cache_sync_ra()
static void page_cache_sync_ra(struct address_space *mapping,
struct folio *folio, pgoff_t offset)
{
// Check if this looks like sequential access
if (offset != folio->index + 1)
return; // Not sequential — don't readahead
// Calculate how many pages to prefetch
unsigned long ra_pages = inode->i_ra_pages; // Adaptive window
// Prefetch pages into cache
page_cache_sync_readahead(mapping, folio, offset, ra_pages);
}page_cache_async_ra(): Asynchronous Readahead
// mm/filemap.c — page_cache_async_ra()
static void page_cache_async_ra(struct address_space *mapping,
struct folio *folio, pgoff_t offset)
{
// Only readahead if we're at the start of a readahead window
if (offset != readahead_offset(mapping, folio))
return;
// Double the readahead window (up to max)
unsigned long new_ra = min(inode->i_ra_pages * 2, VM_MAX_READAHEAD);
inode->i_ra_pages = new_ra;
// Submit async I/O for the readahead window
page_cache_async_readahead(mapping, folio, offset, new_ra);
}Adaptive Readahead Algorithm
The kernel dynamically adjusts the readahead window based on access patterns:
Initial read: ra_pages = 32 pages (128 KB)
Sequential hit: ra_pages = 64 pages (256 KB)
Sequential hit: ra_pages = 128 pages (512 KB)
...
Maximum: ra_pages = 2048 pages (8 MB)
Random access: ra_pages = 0 (no readahead)
This exponential growth means sequential reads quickly reach maximum throughput, while random reads don't waste I/O on useless prefetching.
Writeback: Delayed Disk Writes
The Problem: Write Amplification
Writing each 4KB page individually to disk is inefficient. A single 1MB write is 10x faster than 256 individual 4KB writes. Writeback delays writes to batch them:
// mm/page-writeback.c — writeback_single_inode()
static int writeback_single_inode(struct inode *inode,
struct writeback_control *wbc)
{
struct address_space *mapping = inode->i_mapping;
struct folio *folio;
unsigned long start = wbc->range_start;
unsigned long end = wbc->range_end;
int written = 0;
// Scan for dirty pages
while ((folio = filemap_get_folia_tag(mapping, &start, PAGECACHE_TAG_DIRTY,
end))) {
// Write the dirty page to disk
written += filemap_writepage(folio, wbc);
// Update writeback position
mapping->writeback_index = start + 1;
}
// Wait for I/O to complete
if (wbc->sync_mode == WB_SYNC_ALL)
filemap_fdatawait_range(mapping, wbc->range_start, wbc->range_end);
return written;
}Dirty Page Tracking
Dirty pages are tagged in the xarray for efficient scanning:
// mm/filemap.c — filemap_set_folio_dirty()
void filemap_set_folio_dirty(struct folio *folio)
{
struct address_space *mapping = folio->mapping;
// Mark page as dirty in xarray
xa_lock_irq(&mapping->i_pages);
__xa_set_mark(&mapping->i_pages, folio->index, PAGECACHE_TAG_DIRTY);
xa_unlock_irq(&mapping->i_pages);
// Mark inode as dirty
__mark_inode_dirty(mapping->host, I_DIRTY_PAGES);
}The PAGECACHE_TAG_DIRTY tag allows the kernel to efficiently scan only dirty pages (skipping clean cached pages) during writeback.
Writeback Triggers
Writeback is triggered by three mechanisms:
-
Time-based: Every
dirty_writeback_centisecs(default 500 = 5 seconds), thewb_workfn()kernel thread wakes up and flushes old dirty pages. -
Ratio-based: When dirty pages exceed
dirty_ratio(default 20%) of total memory, new writes block until writeback catches up. -
Explicit:
fsync(),sync(), ormsync()force immediate writeback.
Deep Detail: xarray Tagged Iteration
The xarray supports "tagged" iteration — efficiently scanning only pages with a specific tag:
// mm/filemap.c — filemap_get_folia_tag()
struct folio *filemap_get_folia_tag(struct address_space *mapping,
pgoff_t *index, int tag, pgoff_t max)
{
XA_STATE(xas, &mapping->i_pages, *index);
struct folio *folio;
rcu_read_lock();
folio = xa_find_next_marked(&xas, max, tag);
rcu_read_unlock();
if (folio)
*index = folio->index;
return folio;
}This is how writeback efficiently finds dirty pages without scanning the entire page cache. The xarray's tagged iteration skips non-dirty pages in O(1) per skip.
How to Observe Page Cache Behavior
Using bpftrace
#!/usr/bin/env bpftrace
// trace_page_cache.bt
kprobe:pagecache_get_page
{
@lookups[comm] = count();
}
kprobe:filemap_read
{
@reads[comm] = count();
}
kprobe:page_cache_sync_ra
{
@readahead[comm] = count();
}
kprobe:writeback_single_inode
{
@writeback[comm] = count();
}
END
{
printf("\nPage cache lookups:\n");
print(@lookups);
printf("\nReadahead triggers:\n");
print(@readahead);
}Using /proc
// Page cache statistics
grep -E "Cached|Buffers|Dirty|Writeback" /proc/meminfo
// Per-file page cache
cat /proc/<pid>/smaps | grep -E "Rss|Shared|Private"
// Drop page cache (for testing)
echo 3 > /proc/sys/vm/drop_cachesUsing perf
// Profile page cache misses
perf stat -e dTLB-load-misses,iTLB-load-misses ./benchmark_io
// Trace block I/O
blktrace -d /dev/sda -o - | blkparse -i -Frequently Asked Questions
How much RAM does the page cache use?
Linux uses almost all "free" RAM for page cache. This is normal and desirable — cached pages can be instantly reclaimed when applications need memory. Check Cached in /proc/meminfo.
Why is write() instant but fsync() slow?
write() only copies data to the page cache (RAM). fsync() forces the data to disk, which requires actual I/O. The kernel delays disk writes for 5-30 seconds to batch them efficiently.
What is readahead and how does it work?
Readahead detects sequential access patterns and prefetches data before it's requested. The kernel doubles the readahead window on each sequential hit, up to a maximum of ~8 MB.
How does the kernel find dirty pages for writeback?
Dirty pages are tagged with PAGECACHE_TAG_DIRTY in the xarray. Writeback scans only tagged pages, skipping clean cached pages efficiently.
What happens when the system runs out of memory?
The kernel reclaims clean cached pages first (no I/O needed). If more memory is needed, it writes dirty pages to disk (writeback) and then reclaims them.
Conclusion
The page cache is Linux's secret to fast file I/O. Most reads never touch the disk — they're served from RAM in microseconds. Readahead predicts sequential access and prefetches data, achieving near-disk-maximum throughput. Writeback delays disk writes to batch them efficiently, at the risk of data loss on power failure.
For production systems, the practical takeaways are: "free" RAM is wasted RAM (Linux uses it for cache), write() doesn't mean data is on disk (use fsync() for durability), and understanding readahead helps optimize sequential I/O workloads.
Sources
- Linux kernel source,
mm/filemap.c,filemap_read() - Linux kernel source,
mm/filemap.c,pagecache_get_page() - Linux kernel source,
mm/filemap.c,page_cache_sync_ra() - Linux kernel source,
mm/page-writeback.c,writeback_single_inode() - Linux kernel source,
include/linux/fs.h,struct address_space - Linux kernel source,
include/linux/xarray.h
