When Sockets Form Cycles — Unix Domain Socket Garbage Collection

Every Unix developer knows domain sockets for local IPC. But few know that the kernel has a garbage collector for sockets. Not for memory — for socket reference cycles.

When processes pass file descriptors to each other via SCM_RIGHTS, the sockets they reference can form cycles: socket A references socket B, which references socket C, which references socket A. If no process has a file descriptor to any of these sockets, they're unreachable — but they won't be freed because they reference each other.

This article walks through the Unix domain socket GC source in net/unix/garbage.c to explain how the kernel detects and reclaims these unreachable socket cycles.

Key Takeaways

• Unix sockets can form reference cycles via SCM_RIGHTS fd passing
• unix_vertex tracks in-degree and adjacency for each socket
• Mark phase: walk from reachable sockets, mark visited
• Sweep phase: reclaim unmarked sockets
• GC triggered every 30 seconds or when socket count exceeds threshold
• Abstract namespace sockets (sun_path[0] == '\0') are also GC'd

The Problem: Socket Cycles

How Cycles Form

  Process A ←── fd ──← Process C
     │                   ↑
     ↓                   │
  Socket A ─── fd ──→ Socket B
                     │
                     ↓
                  Socket C

1. Process A sends fd to Process B (via SCM_RIGHTS)
2. Process B sends fd to Process C
3. Process C sends fd to Process A
4. All processes exit — but sockets still reference each other!

The sockets are unreachable (no process has an fd), but they won't be freed because they reference each other.

Why Not Reference Counting?

Reference counting can't detect cycles. If A→B→C→A, each has refcount ≥ 1, so none would be freed. The kernel needs a tracing GC (mark-and-sweep) to detect unreachable cycles.

The GC Algorithm

// net/unix/garbage.c — unix_gc()
void unix_gc(void)
{
    struct unix_sock *u;
    struct unix_vertex *vertex;
    struct list_head cursor;
    unsigned long flags;

    // Phase 0: Collect all sockets that might be in cycles
    INIT_LIST_HEAD(&cursor);
    list_for_each_entry(u, &unix_socket_list, link) {
        vertex = &unix_sk(u)->vertex;
        if (vertex->degree > 0) {
            // Socket has incoming references — might be in cycle
            list_add(&vertex->edge, &cursor);
        }
    }

    // Phase 1: Mark — walk from reachable sockets
    unix_graph_marks(&cursor);

    // Phase 2: Sweep — reclaim unmarked sockets
    unix_graph_sweep(&cursor);
}

Phase 1: Mark

// net/unix/garbage.c — unix_graph_marks()
static void unix_graph_marks(struct list_head *cursor)
{
    struct unix_sock *u;
    struct unix_vertex *vertex;

    // Start from sockets that are directly reachable (have file descriptors)
    list_for_each_entry(vertex, cursor, edge) {
        u = vertex->sock;
        if (u->file) {
            // This socket has a file descriptor — it's reachable
            __set_bit(UNIX_GC_MARK, &vertex->mark);

            // Walk all sockets reachable from this one
            unix_graph_mark_recursive(vertex, cursor);
        }
    }
}

static void unix_graph_mark_recursive(struct unix_vertex *v,
                                       struct list_head *cursor)
{
    struct unix_vertex *neighbor;

    // Mark all neighbors (sockets referenced by this socket)
    list_for_each_entry(neighbor, &v->edge, edge) {
        if (!__test_and_set_bit(UNIX_GC_MARK, &neighbor->mark)) {
            // Not yet marked — recurse
            unix_graph_mark_recursive(neighbor, cursor);
        }
    }
}

Phase 2: Sweep

// net/unix/garbage.c — unix_graph_sweep()
static void unix_graph_sweep(struct list_head *cursor)
{
    struct unix_vertex *vertex;
    struct unix_sock *u;

    list_for_each_entry(vertex, cursor, edge) {
        u = vertex->sock;

        if (!__test_bit(UNIX_GC_MARK, &vertex->mark)) {
            // Not marked — unreachable! Reclaim it.
            __sk_free(u);
        } else {
            // Marked — reachable, clear mark for next GC
            __clear_bit(UNIX_GC_MARK, &vertex->mark);
        }
    }
}

unix_vertex: The Graph Node

// net/unix/garbage.c
struct unix_vertex {
    struct list_head edge;      // Adjacency list (edges to other sockets)
    struct list_head entry;     // Entry in GC cursor list
    struct unix_sock *sock;     // The socket this vertex represents;
    unsigned long mark;         // GC mark bit
};

struct unix_graph {
    struct list_head vertices;  // All vertices in the graph
    struct list_head edges;     // All edges in the graph
    struct unix_vertex *root;   // Root vertex for marking
};

Each socket that participates in fd passing has a unix_vertex in the GC graph. The vertex tracks:

• edge: List of sockets referenced by this socket
• mark: GC mark bit (set during mark phase, checked during sweep)
• sock: Back-pointer to the socket

Deep Detail: scm_stat and FD Passing

When a process sends file descriptors via SCM_RIGHTS, the kernel attaches scm_stat structures:

// net/unix/scm.c
struct scm_stat {
    struct list_head list;      // List of fds in this message
    int fd;                     // The file descriptor
    struct file *file;          // The file (may be a socket)
};

// During GC, these are also marked
static void unix_mark_scm(struct scm_cookie *scm)
{
    struct scm_fp_list *fpl = scm->fp;
    struct scm_fp *fp;

    list_for_each_entry(fp, &fpl->list, list) {
        if (fp->file && S_ISSOCK(fp->file->f_inode->i_mode)) {
            // This fd points to a socket — mark it
            struct unix_sock *u = unix_sk(fp->file->private_data);
            __set_bit(UNIX_GC_MARK, &u->vertex.mark);
        }
    }
}

This ensures that sockets referenced by in-flight SCM_RIGHTS messages are not incorrectly reclaimed.

How to Observe Unix Socket GC

Using bpftrace

#!/usr/bin/env bpftrace
// trace_unix_gc.bt

kprobe:unix_gc
{
    @gc_runs = count();
}

kprobe:unix_graph_marks
{
    @mark_phase = count();
}

kprobe:unix_graph_sweep
{
    @sweep_phase = count();
}

Using /proc

// Unix domain sockets
cat /proc/net/unix

// Socket statistics
ss -x

// Garbage collection stats
cat /proc/net/unix | wc -l  // Total unix sockets

Frequently Asked Questions

When does the GC run?

Every 30 seconds (configurable), or when the number of unix sockets exceeds a threshold. The timer is managed by unix_gc_timer_fn().

What is SCM_RIGHTS?

A Unix domain socket ancillary message type that allows passing file descriptors between processes. The kernel duplicates the fd and installs it in the receiving process.

What is the abstract namespace?

Unix sockets can be created with sun_path[0] == '\0' — these are not bound to filesystem paths. They're only accessible via file descriptors and are also GC'd.

Can GC cause latency spikes?

Yes. The mark phase walks the entire socket graph, which can be large. The sweep phase frees unreachable sockets. Both phases run with interrupts disabled.

How do I prevent socket cycles?

Design your application to avoid circular fd passing. Use a star topology (central hub) rather than circular references.

Conclusion

Unix domain sockets can form reference cycles via SCM_RIGHTS fd passing. The kernel's mark-and-sweep GC walks the socket graph from reachable sockets, marks them, then sweeps unmarked sockets for reclamation. This is essentially the same algorithm as memory GC — but applied to kernel socket objects.

For production systems, the practical takeaways are: fd passing can create cycles, the GC detects and reclaims unreachable sockets, and understanding the algorithm helps design robust IPC architectures.

Sources

• Linux kernel source, net/unix/garbage.c, unix_gc()
• Linux kernel source, net/unix/garbage.c, unix_graph_marks()
• Linux kernel source, net/unix/garbage.c, unix_graph_sweep()
• Linux kernel source, net/unix/scm.c, unix_mark_scm()
• Linux kernel source, include/net/af_unix.h, unix_sock
