Every Linux developer knows that "everything is a file." But what exactly IS a file in the kernel? The answer involves four distinct data structures that work together: struct inode (the file's identity), struct dentry (its name in a directory), struct file (an open file context), and struct super_block (the filesystem instance). These four structures form the core of the Virtual File System (VFS) layer, and understanding their relationships is essential for understanding how Linux filesystems work.
This article walks through the source in include/linux/fs.h to explain each structure, how they reference each other, and why the kernel needs four separate structures instead of one.
Key Takeaways
- inode = file identity (metadata, permissions, size) — one per file on disk
- dentry = directory entry (name → inode mapping) — cached in dcache hash table
- file = open file context (position, flags, operations) — one per open() call
- super_block = filesystem instance — one per mounted filesystem
- One inode can have multiple dentries (hard links), one dentry can have multiple files (repeated open)
container_ofmacro enables OOP-style inheritance in C
The Myth: "A File is Just an inode"
Many developers equate "file" with "inode." While the inode contains the file's metadata, it's only one piece of the puzzle. Consider what happens when you:
- Create a hard link:
ln file.txt link.txt— two names, one inode - Open a file twice:
fd1 = open("file.txt"); fd2 = open("file.txt")— two file contexts, one inode - Bind mount:
mount --bind /a /b— same inode accessible from two paths
A single structure cannot represent all these relationships. That's why VFS has four.
inode: The File's Identity
The inode represents a file's persistent identity — everything that survives after all file descriptors are closed:
// include/linux/fs.h
struct inode {
umode_t i_mode; // File type & permissions (rwxrwxrwx)
kuid_t i_uid; // Owner UID
kgid_t i_gid; // Owner GID
const struct inode_operations *i_op; // Inode operations (create, mkdir, lookup)
struct super_block *i_sb; // Owning superblock
struct address_space *i_mapping; // Page cache mapping
u64 i_ino; // Inode number (unique within filesystem)
loff_t i_size; // File size in bytes
struct timespec64 i_atime; // Access time
struct timespec64 i_mtime; // Modification time
struct timespec64 i_ctime; // Change time
struct hlist_node i_hash; // Inode hash table node
struct list_head i_lru; // Inode LRU list
struct address_space i_data; // Embedded page cache
union {
struct pipe_inode_info *i_pipe; // Pipe-specific data
struct cdev *i_cdev; // Character device
char *i_link; // Symlink target
};
void *i_private; // Filesystem-specific data (e.g., ext4_inode_info)
};Key Fields
i_mode: File type (regular, directory, symlink, device) and permissionsi_size: File size — updated on write, read on lseek(SEEK_END)i_ino: Inode number — unique within a filesystem (but not across filesystems)i_mapping: Points to the page cache (address_space) for this filei_op: Function table for inode operations (create, mkdir, unlink, lookup)i_fop: Function table for file operations (read, write, mmap, fsync)
The Union Trick
The union at the end of struct inode shares memory between mutually exclusive uses:
- A pipe inode uses
i_pipe - A character device uses
i_cdev - A symlink uses
i_link
This saves memory because a file can only be one type at a time.
dentry: The Name Cache
A dentry (directory entry) represents a name in a directory. It's the kernel's cache of "name → inode" mappings:
// include/linux/dcache.h
struct dentry {
unsigned int d_flags;
seqcount_spinlock_t d_seq; // Per-dentry seqcount for RCU walking
struct hlist_bl_node d_hash; // Lookup hash list
struct dentry *d_parent; // Parent directory
const struct qstr d_name; // Component name
struct inode *d_inode; // Associated inode (NULL = negative)
const struct dentry_operations *d_op;
struct super_block *d_sb; // Root dentry of filesystem
struct lockref d_lockref; // Per-dentry lock + refcount
struct list_head d_lru; // LRU list
struct hlist_node d_sib; // Child of parent list
struct hlist_head d_children; // Our children
union {
struct hlist_node d_alias; // Inode alias list
struct hlist_bl_node d_in_lookup_hash; // In-lookup negatives
struct rcu_head d_rcu;
};
};Key Fields
d_name: The component name (e.g., "file.txt" in "/home/user/file.txt")d_inode: The associated inode (NULL for negative dentries — "file not found")d_parent: Parent directory dentryd_children: Child dentries (for directories)d_alias: Links all dentries pointing to the same inode (hard links)d_lockref: Combined lock + refcount for fasttry_getpaths
Negative Dentries
When a file doesn't exist, the kernel caches this fact as a "negative dentry" (d_inode == NULL). This prevents repeated disk I/O for non-existent files.
file: The Open Context
A struct file represents an open file context — everything that's specific to a particular open() call:
// include/linux/fs.h
struct file {
spinlock_t f_lock;
fmode_t f_mode; // FMODE_READ/WRITE/EXEC/CAN_READ/CAN_WRITE/...
const struct file_operations *f_op; // File operations (read, write, mmap)
struct address_space *f_mapping; // Page cache mapping
void *private_data; // Filesystem-specific (e.g., file->private_data for pipes)
struct inode *f_inode; // Associated inode
unsigned int f_flags; // O_NONBLOCK, O_APPEND, O_DIRECT, etc.
loff_t f_pos; // File offset (current read/write position)
struct path f_path; // (dentry, vfsmount) pair
file_ref_t f_ref; // Reference count
struct file_ra_state f_ra; // Readahead state
};Key Fields
f_pos: Current file offset — advanced by read/write operationsf_flags: Open flags (O_NONBLOCK, O_APPEND, O_DIRECT, O_SYNC)f_mode: Access mode (read, write, exec) — checked at open timef_op: Function table for file operations (read, write, mmap, fsync, poll)f_ref: Reference count — file stays open until all fds are closedf_ra: Readahead state — tracks sequential access patterns
Why Separate from inode?
Multiple open() calls create multiple struct file instances, each with its own f_pos and f_flags. This is why two processes can read the same file at different positions simultaneously.
super_block: The Filesystem Instance
A super_block represents a mounted filesystem instance:
// include/linux/fs.h
struct super_block {
struct list_head s_list; // All superblocks list
dev_t s_dev; // Device identifier
unsigned char s_blocksize_bits;// Block size as power of 2
loff_t s_maxbytes; // Maximum file size
struct file_system_type *s_type; // Filesystem type (ext4, xfs, etc.)
const struct super_operations *s_op; // Superblock operations (write_inode, put_super)
unsigned long s_flags; // SB_RDONLY, SB_SYNCHRONOUS, etc.
unsigned long s_magic; // Magic number (EXT4_SUPER_MAGIC = 0xEF53)
struct dentry *s_root; // Root dentry of filesystem
struct rw_semaphore s_umount; // Unmount semaphore
atomic_t s_active; // Active reference count
void *s_fs_info; // Filesystem-specific data (ext4_sb_info, etc.)
struct list_lru s_dentry_lru; // Dentry LRU for this sb
struct list_lru s_inode_lru; // Inode LRU for this sb
struct list_head s_inodes; // All inodes
struct shrinker *s_shrink; // Per-sb shrinker
};Key Fields
s_type: Filesystem type (ext4, xfs, btrfs, etc.)s_root: Root dentry of the mounted filesystems_op: Superblock operations (write_inode, put_super, sync_fs)s_fs_info: Filesystem-specific data (e.g., ext4_sb_info for ext4)s_dentry_lru/s_inode_lru: LRU lists for shrinking cached dentries/inodes
The Relationship Network
┌─────────────────────────────────────────────────────────────────────┐
│ super_block │
│ (filesystem) │
│ │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ inode (file identity) │ │
│ │ (one per file on disk) │ │
│ │ │ │
│ │ ┌─────────────────────────────────────────────────────────┐ │ │
│ │ │ dentry (name → inode mapping) │ │ │
│ │ │ (one per name, cached in dcache) │ │ │
│ │ │ │ │ │
│ │ │ ┌───────────────────────────────────────────────────┐ │ │ │
│ │ │ │ file (open file context) │ │ │ │
│ │ │ │ (one per open() call) │ │ │ │
│ │ │ └───────────────────────────────────────────────────┘ │ │ │
│ │ │ ┌───────────────────────────────────────────────────┐ │ │ │
│ │ │ │ file (another open context) │ │ │ │
│ │ │ │ (different fd, different f_pos) │ │ │ │
│ │ │ └───────────────────────────────────────────────────┘ │ │ │
│ │ └─────────────────────────────────────────────────────────┘ │ │
│ │ ┌─────────────────────────────────────────────────────────┐ │ │
│ │ │ dentry (hard link name) │ │ │
│ │ │ (different name, same inode) │ │ │
│ │ └─────────────────────────────────────────────────────────┘ │ │
│ └───────────────────────────────────────────────────────────────┘ │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ inode (another file) │ │
│ └───────────────────────────────────────────────────────────────┘ │
└─────────────────────────────────────────────────────────────────────┘
Many-to-Many Relationships
- One inode → multiple dentries: Hard links (
ln file.txt link.txt) - One dentry → multiple files: Repeated
open()calls - One super_block → multiple inodes: All files in a filesystem
- One inode → one super_block: An inode belongs to exactly one filesystem
Deep Detail: container_of Inheritance
Linux uses the container_of macro to implement OOP-style inheritance in C:
// include/linux/container_of.h
#define container_of(ptr, type, member) \
((type *)((char *)(ptr) - offsetof(type, member)))Examples
// From struct sock to struct tcp_sock
static inline struct tcp_sock *tcp_sk(const struct sock *sk)
{
return container_of(sk, struct tcp_sock, inet_conn);
}
// From struct sock to struct unix_sock
static inline struct unix_sock *unix_sk(const struct sock *sk)
{
return container_of(sk, struct unix_sock, sk);
}
// From struct inode to struct mqueue_inode_info
static inline struct mqueue_inode_info *MQUEUE_I(struct inode *inode)
{
return container_of(inode, struct mqueue_inode_info, vfs_inode);
}This pattern allows the kernel to embed a generic structure (like struct sock) inside a specific structure (like tcp_sock), and recover the specific structure from a pointer to the generic one.
How to Observe VFS Structures
Using bpftrace
#!/usr/bin/env bpftrace
// trace_vfs.bt
kprobe:d_alloc
{
@dentry_alloc[comm] = count();
}
kprobe:d_lookup
{
@dentry_lookup[comm] = count();
}
kprobe:alloc_inode
{
@inode_alloc[comm] = count();
}
kprobe:open_exec
{
@exec[comm] = count();
}Using /proc and /sys
// Dcache statistics
cat /proc/sys/fs/dentry-state
// Inode cache statistics
cat /proc/sys/fs/inode-nr
// Filesystem information
cat /proc/mounts
cat /proc/self/mountinfo
// Per-process open files
ls -la /proc/<pid>/fd/Using debugfs
// Ext4 inode info (if debugfs mounted)
cat /sys/kernel/debug/ext4/<partition>/inode_cacheFrequently Asked Questions
What is the difference between a hard link and a symlink?
A hard link is a second dentry pointing to the same inode. A symlink is a special file containing a path string. Hard links share the same inode (same permissions, size, data); symlinks have their own inode.
Why does rm not free disk space immediately?
rm only removes the dentry (name → inode mapping). The inode and its data are freed only when the link count reaches zero AND no file descriptors reference it.
What happens when a file is deleted while open?
The dentry is removed (the name disappears), but the inode persists until all file descriptors are closed. The process can still read/write via its open fd.
How does dup() work?
dup() creates a new file descriptor that points to the same struct file. Both fds share the same file offset and flags.
What is the difference between O_RDONLY and FMODE_READ?
O_RDONLY is a user-space flag passed to open(). FMODE_READ is the kernel-internal representation stored in file->f_mode.
Conclusion
The four VFS structures — inode, dentry, file, and super_block — work together to represent files in Linux. The inode is the file's identity, the dentry is its name in a directory, the file is an open context, and the super_block is the filesystem instance. Their many-to-many relationships (hard links, repeated opens, bind mounts) are what make Linux's filesystem layer flexible and powerful.
Understanding these structures is essential for filesystem development, performance tuning, and debugging. The practical takeaways are: hard links share inodes, repeated opens create separate file contexts, and the container_of macro enables the OOP-style inheritance that makes the VFS layer possible.
