How Hard Is It to Wake Up a Process? — CPU Selection Logic Behind try_to_wake_up()
How Hard Is It to Wake Up a Process? — CPU Selection Logic Behind try_to_wake_up()
Every developer knows that waking a sleeping process involves setting it to TASK_RUNNING and adding it to a runqueue. But the real complexity lies in a question most never consider: which CPU should this process run on?
On a 64-core server, the choice of CPU can mean the difference between a process resuming with warm L1 cache (0.5 ns access) or cold cache requiring NUMA remote memory access (100+ ns). The kernel's wake-up path must balance four competing objectives: cache affinity (run where it last ran), load balancing (run where it's least loaded), power efficiency (consolidate onto fewer cores), and NUMA locality (run near its memory).
This article walks through the wake-up source in kernel/sched/core.c to explain how the kernel makes this decision, why the "obvious" choice is often wrong, and how select_task_rq_fair() navigates the trade-offs.
Key Takeaways
- Wake-up involves 4 stages: state check, CPU selection, queue insertion, preemption check
pi_lockserializes wakeup with schedule to prevent racesselect_task_rq_fair()balances cache affinity, load, power, and NUMAwake_affine()biases toward the previous CPU for cache warmth- sched_domain hierarchy: DMC → MC → DIE → NUMA (smallest to largest)
- Proxy execution lets a high-priority task "donate" its CPU to a lower-priority task
The Four Stages of Wake-up
wake_up_process() / try_to_wake_up()
│
▼
┌─────────────────────────────────────────────────────────────────────┐
│ Stage 1: STATE CHECK │
│ • Acquire pi_lock (serializes with schedule) │
│ • Check ttwu_state_match() — is the task in the expected state? │
│ • If already runnable, bail out (prevent double-enqueue) │
└─────────────────────────────────────────────────────────────────────┘
│
▼
┌─────────────────────────────────────────────────────────────────────┐
│ Stage 2: CPU SELECTION │
│ • prev_cpu = task_cpu(p) — where it last ran │
│ • select_task_rq_fair() — the decision engine │
│ • Fast path: if prev_cpu is idle, use it │
│ • Slow path: find best CPU considering affinity, load, power │
└─────────────────────────────────────────────────────────────────────┘
│
▼
┌─────────────────────────────────────────────────────────────────────┐
│ Stage 3: QUEUE INSERTION │
│ • ttwu_queue() — enqueue on selected CPU's runqueue │
│ • activate_task() → enqueue_task_fair() │
│ • update_load_avg() — update PELT for the target CPU │
└─────────────────────────────────────────────────────────────────────┘
│
▼
┌─────────────────────────────────────────────────────────────────────┐
│ Stage 4: PREEMPTION CHECK │
│ • ttwu_do_wakeup() — check if new task should preempt current │
│ • check_preempt_curr() → resched_curr_lazy() if needed │
└─────────────────────────────────────────────────────────────────────┘
Stage 1: try_to_wake_up() — State Check
// kernel/sched/core.c — try_to_wake_up()
int try_to_wake_up(struct task_struct *p, unsigned int state, int wake_flags)
{
int cpu, success = 0;
// Prevent concurrent schedule() from interfering
scoped_guard(raw_spinlock_irqsave, &p->pi_lock) {
// Check if task is in the expected state
if (!ttwu_state_match(p, state, &success))
break;
// Task is in expected state — proceed with wakeup
cpu = select_task_rq(p, p->wake_cpu, wake_flags);
}
// Queue the task on the selected CPU
ttwu_queue(p, cpu, wake_flags);
return success;
}The Role of pi_lock
pi_lock (priority inheritance lock) serves double duty:
- It protects the task's scheduling state during wakeup
- It serializes with
schedule()— preventing a race where a task is both being woken up and being scheduled away
Without pi_lock, this race could occur:
CPU 0: try_to_wake_up() CPU 1: schedule()
reads p->state = TASK_RUNNING sets p->state = TASK_SLEEPING
selects CPU for wakeup picks next task
enqueue on runqueue (task is now on runqueue AND sleeping)
ttwu_state_match(): Preventing Double-Wakeup
// kernel/sched/core.c
static inline bool ttwu_state_match(struct task_struct *p, unsigned int state, int *success)
{
if (!(p->state & state))
return false;
*success = 1;
return true;
}If the task is already runnable (e.g., another CPU woke it up first), ttwu_state_match() returns false and the wakeup is aborted.
Stage 2: select_task_rq_fair() — The Decision Engine
This is where the kernel decides which CPU the woken task should run on:
// kernel/sched/fair.c — select_task_rq_fair()
static int select_task_rq_fair(struct task_struct *p, int prev_cpu, int wake_flags)
{
// Fast path: prev_cpu is idle — use it
if (available_idle_cpu(prev_cpu))
return prev_cpu;
// Find the best CPU in the scheduling domain
int new_cpu = find_idlest_cpu(p, prev_cpu, wake_flags);
// Apply wake_affine bias (prefer prev_cpu for cache warmth)
if (wake_flags & WF_SYNC && prev_cpu == smp_processor_id())
return prev_cpu; // Sync wakeup: prefer waker's CPU
return new_cpu;
}wake_affine(): Cache Warmth vs Load
// kernel/sched/fair.c — wake_affine()
static int wake_affine(struct sched_domain *sd, struct task_struct *p,
int this_cpu, int prev_cpu, int sync)
{
int want_affine = 0;
// If the waker and wakee share cache, prefer affine
if (cpu_share_cache(this_cpu, prev_cpu))
want_affine = 1;
// If prev_cpu has spare capacity, prefer it
if (want_affine && cfs_rq_idle_capacity(prev_cpu) > 0)
return prev_cpu;
// Otherwise, let find_idlest_cpu decide
return this_cpu;
}The key insight: cache warmth often outweighs load. A process waking on its previous CPU benefits from:
- Warm L1/L2 cache (the process's working set is still there)
- Warm TLB entries (address translations cached)
- No cache-line migration overhead
find_idlest_cpu(): The Hierarchical Search
// kernel/sched/fair.c — find_idlest_cpu()
static int find_idlest_cpu(struct task_struct *p, int prev_cpu, int wake_flags)
{
struct sched_domain *sd;
int best_cpu = prev_cpu;
int cpu = smp_processor_id();
// Walk sched_domain hierarchy from smallest to largest
for_each_domain(prev_cpu, sd) {
if (sd->flags & SD_WAKE_AFFINE) {
// Try to find an idle CPU in this domain
cpu = find_idlest_group(sd, p, prev_cpu);
if (cpu != -1) {
best_cpu = cpu;
break;
}
}
}
return best_cpu;
}The sched_domain Hierarchy
┌─────────────────────────────────────────────────────────────────────┐
│ NUMA Domain (largest) │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ DIE Domain (package) │ │
│ │ ┌─────────────────────────────────────────────────────────┐ │ │
│ │ │ MC Domain (multi-core) │ │ │
│ │ │ ┌───────────────────────────────────────────────────┐ │ │ │
│ │ │ │ DMC Domain (multi-core, shared L2) │ │ │ │
│ │ │ │ ┌─────────────────────────────────────────────┐ │ │ │ │
│ │ │ │ │ SMT Domain (hyper-threading) │ │ │ │ │
│ │ │ │ │ CPU0 CPU1 CPU2 CPU3 CPU4 CPU5 ... │ │ │ │ │
│ │ │ │ └─────────────────────────────────────────────┘ │ │ │ │
│ │ │ └───────────────────────────────────────────────────┘ │ │ │
│ │ └─────────────────────────────────────────────────────────┘ │ │
│ └───────────────────────────────────────────────────────────────┘ │
└─────────────────────────────────────────────────────────────────────┘
The kernel searches from smallest domain (SMT) to largest (NUMA):
- SMT domain: Try sibling hyper-threads (shared L1/L2)
- DMC domain: Try cores sharing L2 cache
- MC domain: Try cores in the same multi-core package
- DIE domain: Try dies in the same package
- NUMA domain: Try nodes in the same NUMA zone
The first domain with an idle CPU wins. This ensures maximum cache reuse.
Stage 3: ttwu_queue() — Queue Insertion
// kernel/sched/core.c — ttwu_queue()
static void ttwu_queue(struct task_struct *p, int cpu, int wake_flags)
{
struct rq *rq = cpu_rq(cpu);
// Lock the target runqueue
rq_lock(rq, &rf);
// Update runqueue clock
update_rq_clock(rq);
// Activate task on target CPU
activate_task(rq, p, ENQUEUE_WAKEUP);
// Check for preemption
ttwu_do_wakeup(rq, p, wake_flags);
rq_unlock(rq, &rf);
}activate_task(): The Actual Enqueue
// kernel/sched/core.c
void activate_task(struct rq *rq, struct task_struct *p, int flags)
{
enqueue_task(rq, p, flags);
WRITE_ONCE(p->on_rq, TASK_ON_RQ_QUEUED);
}
void enqueue_task(struct rq *rq, struct task_struct *p, int flags)
{
update_rq_clock(rq);
uclamp_rq_inc(rq, p, flags); // Utilization clamping
p->sched_class->enqueue_task(rq, p, flags); // Class-specific enqueue
psi_enqueue(p, flags); // Pressure Stall Information
}Stage 4: Preemption Check
// kernel/sched/core.c — ttwu_do_wakeup()
static void ttwu_do_wakeup(struct rq *rq, struct task_struct *p, int wake_flags)
{
// Update task state to TASK_RUNNING
p->state = TASK_RUNNING;
// Check if the woken task should preempt the current task
check_preempt_curr(rq, p, wake_flags);
// Update PELT load tracking
update_load_avg(cfs_rq_of(&p->se), &p->se, 0);
}If the woken task has higher priority (earlier deadline) than the current task, check_preempt_curr() sets TIF_NEED_RESCHED on the current CPU.
Deep Detail: Proxy Execution
Proxy execution is a clever optimization where a high-priority task "donates" its CPU time to a lower-priority task:
// kernel/sched/core.c — check_preempt_curr()
void check_preempt_curr(struct rq *rq, struct task_struct *p, int flags)
{
// If the woken task has higher priority, preempt
if (p->prio < rq->curr->prio) {
resched_curr_lazy(rq);
return;
}
// Proxy execution: if current task is blocked but holds a resource
// that the woken task needs, let the woken task run on this CPU
if (task_on_rq_queued(rq->curr) && rq->curr->on_rq == TASK_ONQ_QUEUED) {
// Check if proxy execution applies
if (task_is_proxy(rq->curr, p)) {
resched_curr_lazy(rq);
}
}
}This prevents priority inversion: a high-priority task waiting for a lock held by a low-priority task can "donate" its CPU to the lock holder.
How to Observe Wake-up Behavior
bpftrace Script
#!/usr/bin/env bpftrace
// trace_wakeup.bt
kprobe:try_to_wake_up
{
@wake[comm] = count();
@start = nsecs;
}
kprobe:select_task_rq_fair
{
$prev = arg1;
printf("[%s] wakeup: prev_cpu=%d\n", comm, $prev);
}
kretprobe:select_task_rq_fair
{
printf("[%s] selected cpu=%d (prev=%d)\n", comm, $retval, ((struct task_struct *)arg0)->wake_cpu);
}
tracepoint:sched:sched_wakeup
{
@target_cpu[args->pid] = args->target_cpu;
}
tracepoint:sched:sched_wakeup_new
{
@new_wake[comm] = count();
}Reading sched_debug
// Per-CPU runqueue info
cat /sys/kernel/debug/sched/debug | grep -A5 "cpu#"
// Sched domain topology
cat /sys/kernel/debug/sched/domains/cpu0/domain*/name
// Wake-affine statistics
cat /proc/sys/kernel/sched_domain/cpu0/domain*/wake_affineFrequently Asked Questions
Why doesn't the kernel always wake to an idle CPU?
Because an idle CPU means cold cache. The woken process's working set is still on the previous CPU's L1/L2 cache. Waking to the previous CPU (even if busy) is often faster due to cache warmth. The kernel only uses idle CPUs when the previous CPU is heavily loaded.
What is WF_SYNC?
WF_SYNC is a wakeup flag indicating the waker expects the wakee to run soon (e.g., wake_up_process() from an interrupt handler). It biases selection toward the waker's CPU for cache warmth.
How does NUMA topology affect wake-up?
On NUMA systems, the kernel prefers to wake a process on the same NUMA node as its memory. Remote NUMA access is 2-3x slower than local access. The NUMA domain in the sched_domain hierarchy enforces this.
What is sched_idle_cpu()?
A CPU that is currently running the idle task. The kernel tracks idle CPUs per sched_domain for fast wake-up placement.
How does load balancing interact with wake-up?
Wake-up placement is a "pull" decision (where should this task run?). Load balancing is a "push" decision (should tasks move between CPUs?). They work together: wake-up places tasks optimally, load balancing corrects imbalances over time.
Conclusion
Waking a process is far more complex than setting it runnable. The kernel must choose which CPU to run on, balancing four competing objectives: cache affinity, load distribution, power efficiency, and NUMA locality. The select_task_rq_fair() function navigates these trade-offs through the sched_domain hierarchy, from SMT siblings to NUMA nodes.
For production systems, the practical takeaways are: wake-up placement significantly affects performance (cold vs warm cache), wake_affine() biases toward the previous CPU for good reason, and understanding the sched_domain hierarchy helps diagnose scheduling performance issues.
Sources
- Linux kernel source,
kernel/sched/core.c,try_to_wake_up() - Linux kernel source,
kernel/sched/fair.c,select_task_rq_fair() - Linux kernel source,
kernel/sched/fair.c,wake_affine() - Linux kernel source,
kernel/sched/fair.c,find_idlest_cpu() - Linux kernel source,
kernel/sched/sched.h,sched_domain
