How Does the FUSE Kernel Module Work? A Software Engineer's Code Walkthrough

Every FUSE filesystem has two halves. The userspace half — libfuse — implements the filesystem logic. The kernel half — the FUSE kernel module at fs/fuse/ in the Linux source — is the gatekeeper that intercepts every VFS call and decides whether to handle it locally or forward it to userspace. If our companion post on libfuse explained the userspace library, this one explains the kernel side.

The problem is that the kernel module is dense: roughly 13,000+ lines of C across 30+ files, with complex request lifecycle management, two transport layers (/dev/fuse and io_uring), and a steady stream of recent high-performance features — passthrough, writeback cache, request timeouts — that change how FUSE works. And unlike libfuse (which is in limited-maintenance mode), the kernel module is actively developed, creating a growing capability gap between the two halves.

This article walks through the kernel module source top-down: the core data structures, the request lifecycle, the transport layers, and the recent features that bypass userspace entirely. By the end you will understand the kernel side of FUSE well enough to read dev.c (the 2430-line /dev/fuse transport) and know exactly what each function does.

Key Takeaways

The FUSE kernel module lives at fs/fuse/ in the Linux source — ~13,000+ lines across 30+ files, merged in kernel 2.6.14 (2005), actively maintained by Miklos Szeredi.

Every VFS call goes through a FUSE operation (e.g., fuse_read_iter()) that allocates a fuse_req, enqueues it on the connection's pending queue, and waits. Userspace reads the request from /dev/fuse, processes it, writes the response back, and the kernel wakes up the waiting VFS call.

Three core objects: fuse_conn (connection), fuse_inode (per-inode), fuse_file (per-open-file). Each connection has an input queue (pending requests), a processing queue (hash table), and a background queue.

FUSE_PASSTHROUGH lets the kernel read/write directly to a backing file, bypassing userspace for data I/O. FUSE_OVER_IO_URING replaces the /dev/fuse read/write with io_uring rings for reduced syscall overhead.

The kernel module is actively developed (passthrough, io_uring, timeouts, DAX, security context) while libfuse is in limited-maintenance mode — a growing gap developers should understand.

What the FUSE Kernel Module Is

FUSE is a split design. The kernel module (fs/fuse/) registers a file_system_type and implements all VFS operations — superblock, inode, file, directory — by forwarding them to userspace. The userspace library (libfuse) reads those requests, dispatches to your filesystem callbacks, and writes responses back. They communicate via the FUSE protocol defined in include/uapi/linux/fuse.h (1311 lines).

This post covers the kernel side. The kernel module does not implement filesystem logic — it implements the gatekeeper: intercepting VFS calls, marshalling them into FUSE protocol messages, sending them to userspace via a transport, and waiting for the response.

Key source files:

File	Lines	Purpose
`fuse_i.h`	1333	Core data structures: fuse_conn, fuse_inode, fuse_file, fuse_chan
`fuse_dev_i.h`	422	Request, channel, queue structures
`dev.c`	2430	/dev/fuse character device transport
`file.c`	3121	File operations (read, write, mmap, ioctl, fsync)
`inode.c`	2190	Inode management, superblock, FUSE_INIT handshake
`dir.c`	2498	Directory operations (lookup, mkdir, readdir, rename)
`dev_uring.c`	1457	FUSE-over-io_uring transport
`passthrough.c`	197	FUSE_PASSTHROUGH direct I/O
`control.c`	367	/sys/fs/fuse/connections control filesystem
`notify.c`	447	Kernel-side notification processing
`req.c`	100	Request allocation and credential helpers
`req_timeout.c`	~150	Request timeout handling
`virtio_fs.c`	~2000	FUSE over virtio for VMs
`dax.c`	~1500	Direct Access (CXL memory)

┌─────────────────────────────────────────────────────────────────────┐
│                         Linux Kernel                                 │
│  ┌─────────┐   ┌──────────────────────────────────────────────┐    │
│  │   VFS   │──►│         FUSE Kernel Module (fs/fuse/)        │    │
│  └─────────┘   │                                              │    │
│       │        │  fuse_read_iter() ──► fuse_send_read()       │    │
│       │        │  fuse_lookup()     ──► fuse_lookup_name()    │    │
│       │        │  fuse_mkdir()      ──► create_new_entry()    │    │
│       │        │  ...                  ...                    │    │
│       │        │                                              │    │
│       │        │  ┌─────────────┐    ┌──────────────────┐    │    │
│       │        │  │ /dev/fuse   │    │ io_uring rings   │    │    │
│       │        │  │ (dev.c)     │    │ (dev_uring.c)    │    │    │
│       │        │  └──────┬──────┘    └────────┬─────────┘    │    │
│       │        └─────────┼────────────────────┼──────────────┘    │
│       │                  │                    │                    │
└───────┼──────────────────┼────────────────────┼────────────────────┘
        │                  │                    │
        │          read() / write()       SQEs / CQEs
        │                  │                    │
        │                  ▼                    ▼
        │         ┌─────────────────────────────────────┐
        │         │     Userspace FUSE Daemon            │
        │         │     (libfuse or custom)              │
        │         └─────────────────────────────────────┘
        │                  │
        │                  ▼
   ┌────┴────┐      ┌────────────┐
   │ App     │      │ Filesystem │
   │ read()  │      │ Logic      │
   └─────────┘      └────────────┘

Core Data Structures

The FUSE kernel module's architecture revolves around six core structures. Understanding them is the key to reading the source.

struct fuse_conn — Per-Connection State

struct fuse_conn (defined in fuse_i.h, ~765 lines of fields) is created at mount time and destroyed when the last mount is gone and /dev/fuse is closed. It holds the connection-wide state:

Synchronization: lock (spinlock protecting polled_files, backing_files_map, curr_bucket), killsb (rw_semaphore for superblock access), count (refcount), epoch (atomic — for dentry cache coherency)
Identity: user_id, group_id, pid_ns, user_ns
I/O limits: max_read, max_write, max_pages, congestion_threshold
Transport: chan (pointer to fuse_chan), khctr (monotonic kernel file-handle counter)
60+ capability bitfields negotiated during FUSE_INIT: writeback_cache, passthrough, async_read, atomic_o_trunc, export_support, big_writes, do_readdirplus, parallel_dirops, posix_acl, default_permissions, allow_other, handle_killpriv_v2, direct_io_allow_mmap, sync_init, no_* feature flags, and many more
State: conn_error, conn_init, abort_err, destroy
Counters: attr_version (atomic64), evict_ctr (atomic64)
Mounts: mounts list (supports submounts sharing one connection)
Write sync: curr_bucket (RCU pointer to fuse_sync_bucket)
Passthrough: backing_files_map (IDR map of backing file IDs)

struct fuse_req — A Kernel Request

struct fuse_req (in fuse_dev_i.h) represents a single request to userspace:

list — queue linkage (pending, processing, or io lists)
intr_entry — entry on the interrupts list
args — input/output arguments (fuse_args)
count — refcount
flags — bitfield of fuse_req_flag: FR_PENDING, FR_SENT, FR_FINISHED, FR_INTERRUPTED, FR_ABORTED, FR_LOCKED, FR_WAITING, FR_BACKGROUND, FR_FORCE, FR_ISREPLY, FR_PRIVATE, FR_ASYNC, FR_URING
in.h — fuse_in_header (opcode, unique ID, nodeid, uid, gid, pid)
out.h — fuse_out_header (error, unique ID)
waitq — wait queue for the requesting thread
chan — owning fuse_chan
create_time — jiffies at creation (for timeout detection)
ring_entry, ring_queue — io_uring pointers

struct fuse_file — Per-Open-File State

struct fuse_file tracks each open file:

fh — userspace file handle (returned by FUSE_OPEN)
kh — unique kernel handle (from khctr)
nodeid — inode this file belongs to
open_flags — FOPEN_* flags from the server
iomode — IOM_NONE, IOM_CACHED, or IOM_UNCACHED
write_entry — entry on the inode's write_files list
readdir.{pos, cache_off, version} — readdir state
polled_node, poll_wait — poll support
passthrough — pointer to backing file (when FUSE_PASSTHROUGH is active)

struct fuse_inode — Per-Inode State

struct fuse_inode embeds struct inode as its first member and adds FUSE-specific state:

nodeid — unique userspace inode ID
nlookup — lookup count (for FORGET)
i_time — attribute cache expiry (jiffies)
inval_mask — which attributes are stale
Write cache (regular files): write_files list, queued_writes, writectr, iocachectr, page_waitq
Readdir cache (directories): rdc.{cached, size, pos, version, mtime, epoch, iversion}
state — bitfield: FUSE_I_ADVISE_RDPLUS, FUSE_I_INIT_RDPLUS, FUSE_I_SIZE_UNSTABLE, FUSE_I_BAD, FUSE_I_BTIME, FUSE_I_CACHE_IO_MODE, FUSE_I_EXCLUSIVE
mutex — serializes lookups/readdir (unless parallel_dirops)
lock — spinlock for write-related fields
fb — fuse_backing pointer (passthrough)

struct fuse_chan — Transport Channel

struct fuse_chan is the transport abstraction:

iq — input queue (fuse_iqueue: pending list, interrupts, forget list, reqctr)
devices — list of fuse_dev instances
max_background, num_background, active_background — background request flow control
bg_queue — background requests awaiting dispatch
initialized — set after FUSE_INIT reply received
blocked — set when too many background requests are pending
connected — cleared on umount/abort
num_waiting — atomic count of waiting requests
io_uring — flag: use io_uring transport
ring — fuse_ring pointer (io_uring state)
timeout.{work, req_timeout} — delayed work + timeout value

struct fuse_iqueue and struct fuse_pqueue

fuse_iqueue — the input queue: reqctr (unique ID counter), pending list, interrupts list, forget_list_head/tail, forget_batch, ops (send_forget, send_interrupt, send_req, release callbacks)
fuse_pqueue — the processing queue: hash table of requests being processed (FUSE_PQ_HASH_BITS = 8, so 256 buckets), io list

Server room with blinking lights, representing the kernel infrastructure that manages FUSE request queues and connections

The Request Lifecycle: From VFS Call to Userspace and Back

This is the heart of the module. Every filesystem operation — read(), write(), stat(), ls — follows the same path. Here is a read() traced end-to-end through the actual source:

┌──────────────┐     ┌───────────────────┐     ┌──────────────────┐     ┌────────────────┐
│  Application │     │  FUSE Kernel      │     │  /dev/fuse       │     │  Userspace     │
│  read()      │     │  (file.c)         │     │  (dev.c)         │     │  Daemon        │
└──────┬───────┘     └────────┬──────────┘     └────────┬─────────┘     └───────┬────────┘
       │                      │                          │                        │
       │  read(fd, buf, n)    │                          │                        │
       ├─────────────────────►│  fuse_file_read_iter()   │                        │
       │                      │  → fuse_cache_read_iter()│                        │
       │                      │  → fuse_read_folio()     │                        │
       │                      │  → fuse_send_read()      │                        │
       │                      │                          │                        │
       │                      │  fuse_request_alloc()    │                        │
       │                      │  set FR_PENDING          │                        │
       │                      │  fill FUSE_READ args     │                        │
       │                      │                          │                        │
       │                      │  fuse_chan_send()        │                        │
       │                      │  → fuse_dev_queue_req()  │                        │
       │                      │  → enqueue on fiq->pending│                       │
       │                      │  → fuse_dev_wake_and_unlock()                     │
       │                      │  ─── wake up reader ───►│  fuse_dev_read()       │
       │                      │                          │  → fuse_dev_do_read()  │
       │                      │                          │  → copy request to     │
       │                      │                          │    userspace buffer     │
       │                      │                          ├───────────────────────►│
       │                      │                          │                        │  (process read)
       │                      │                          │  fuse_dev_write()      │
       │                      │                          │  ←── response ─────────┤
       │                      │                          │  → fuse_request_find() │
       │                      │                          │    (hash by unique ID) │
       │                      │                          │  → fuse_request_end()  │
       │                      │                          │    set FR_FINISHED     │
       │                      │  ◄── wake_up(req->waitq) │                        │
       │  return bytes        │                          │                        │
       ◄──────────────────────┤                          │                        │

Step-by-step through the source

1. VFS dispatches to FUSE. fuse_file_read_iter() (file.c:1823) checks the open mode: DAX → fuse_dax_read_iter, FOPEN_DIRECT_IO → fuse_direct_read_iter, passthrough → fuse_passthrough_read_iter, otherwise → fuse_cache_read_iter().

2. Build the request. fuse_cache_read_iter() calls fuse_read_folio() which batches folios and calls fuse_send_read() (file.c:794). This fills fuse_read_in args and calls fuse_simple_request().

3. Allocate and send. fuse_simple_request() (req.c:60) calls fuse_req_prep() (fills credentials) then fuse_chan_send() (dev.c:809). This allocates a fuse_req from the slab cache (fuse_request_alloc()), sets FR_PENDING, records create_time, and calls __fuse_request_send().

4. Queue and wake userspace. fuse_dev_queue_req() (dev.c:282) assigns a unique ID (from fiq->reqctr), appends the request to fiq->pending, and calls fuse_dev_wake_and_unlock() which wakes the fiq->waitq (where the userspace daemon is blocked in fuse_dev_read()) and sends SIGIO via kill_fasync().

5. Wait for response. request_wait_answer() (dev.c:697) does a three-phase wait: (1) wait_event_interruptible — interruptible by any signal; if interrupted, sets FR_INTERRUPTED and sends an interrupt if the request was already FR_SENT. (2) wait_event_killable — only fatal signals. (3) Unconditional wait_event until FR_FINISHED.

6. Userspace reads. fuse_dev_read() (dev.c:1680) → fuse_dev_do_read() (dev.c:1516) loops on fiq->waitq (exclusive wait) until a request is available. Priority: interrupts → forgets → normal requests. For a normal request: removes from fiq->pending, clears FR_PENDING, copies to fpq->io, copies header + args to userspace via fuse_copy_args(), moves to fpq->processing[hash], sets FR_SENT.

7. Userspace writes response. fuse_dev_write() (dev.c:1968) → fuse_dev_do_write() (dev.c:1860) copies the fuse_out_header. If oh.unique == 0, it's a notification → fuse_notify(). Otherwise: looks up the request by unique ID via fuse_request_find() (hash table lookup), copies the payload with fuse_copy_out_args(), then calls fuse_request_end().

8. Complete the request. fuse_request_end() (dev.c:628) sets FR_FINISHED, handles interrupt cleanup, wakes req->waitq, and drops the reference. The waiting VFS call returns.

Background requests

Not all requests block the caller. Background requests (FORGET, BATCH_FORGET, interrupts) go through fuse_chan_send_bg() → fuse_request_queue_background(). The bg_queue + num_background + congestion_threshold provide flow control: when num_background >= congestion_threshold, new foreground requests block until background requests complete.

The FUSE_INIT Handshake

When a FUSE filesystem is mounted, the kernel and userspace daemon must agree on protocol version and capabilities. This happens via the FUSE_INIT handshake:

Kernel sends INIT. fuse_send_init() (inode.c:1504) builds the request via fuse_new_init() (inode.c:1440), which sets:
- FUSE_KERNEL_VERSION = 7, minor (latest)
- max_readahead, max_write, max_pages
- A large OR-mask of supported flags: FUSE_ASYNC_READ, FUSE_POSIX_LOCKS, FUSE_ATOMIC_O_TRUNC, FUSE_EXPORT_SUPPORT, FUSE_BIG_WRITES, FUSE_AUTO_INVAL_DATA, FUSE_DO_READDIRPLUS, FUSE_WRITEBACK_CACHE, FUSE_PARALLEL_DIROPS, FUSE_POSIX_ACL, FUSE_MAX_PAGES, FUSE_PASSTHROUGH, FUSE_OVER_IO_URING, FUSE_REQUEST_TIMEOUT, and more
Userspace replies. The daemon responds with the intersection of supported capabilities.
Kernel processes reply. process_init_reply() (inode.c:1269) validates arg->major == FUSE_KERNEL_VERSION, decodes the reply flags into fc feature bits, calls process_init_limits() (caps max_background/congestion_threshold for unprivileged users), sets conn_init/conn_error, and calls fuse_chan_set_initialized() which wakes blocked_waitq (allowing request allocation to proceed).

Citation capsule: The FUSE_INIT handshake negotiates protocol capabilities between kernel and userspace. The kernel advertises a superset of supported flags (FUSE_ASYNC_READ, FUSE_WRITEBACK_CACHE, FUSE_PASSTHROUGH, FUSE_OVER_IO_URING, etc.); userspace replies with the intersection. The connection is blocked until the INIT reply is received — fch->initialized gates all request allocation (fuse_conn_init / process_init_reply, fs/fuse/inode.c).

Synchronous FUSE_INIT

The sync_init mount option (and the FUSE_DEV_IOC_SYNC_INIT ioctl) enables synchronous initialization. This is needed for SELinux, which may send getattr requests before fuse_send_init() completes. With sync init, a worker thread processes requests during the mount handshake.

The Transport Layer: /dev/fuse

The classic transport is a misc character device /dev/fuse. The implementation lives in dev.c (2430 lines).

Device lifecycle

fuse_dev_init() — creates the fuse_req_cachep slab cache and registers fuse_miscdevice
fuse_dev_open() — allocates a fuse_dev, stores in file->private_data
fuse_dev_release() — atomically detaches the channel (xchg(&fud->chan, FUSE_DEV_CHAN_DISCONNECTED)), ends all processing requests, and if this is the last device, calls fuse_chan_abort()

The copy engine

Data moves between kernel and userspace via fuse_copy_state and its functions:

fuse_copy_one() — copy a single value
fuse_copy_args() — copy request header + arguments to userspace
fuse_copy_folio() — copy folio data (with page-stealing optimization via fuse_try_move_folio())
fuse_copy_out_args() — copy response payload from userspace
fuse_copy_fill() / fuse_copy_do() — the actual copy loop

Interrupts

FUSE_INTERRUPT (odd unique ID) cancels an in-flight request. queue_interrupt() (dev.c:666) calls fiq->ops->send_interrupt() → fuse_dev_queue_interrupt() (dev.c:240), which adds the request to fiq->interrupts and wakes readers. The interrupted request's waiter is woken with -EINTR.

Connection abort

Writing to /sys/fs/fuse/connections/<n>/abort triggers fuse_chan_abort() (dev.c:2129): sets fch->connected = 0, iterates all devices' processing queues, marks requests FR_ABORTED, finishes unlocked requests, flushes the bg queue, and wakes everyone.

The io_uring Transport (FUSE_OVER_IO_URING)

dev_uring.c (1457 lines) implements FUSE-over-io_uring — a high-performance transport that replaces read/write on /dev/fuse with io_uring shared ring buffers.

How it differs from classic transport

CLASSIC (/dev/fuse)                    IO_URING
────────────────────                    ─────────
  read() = fetch request                FUSE_IO_URING_CMD_REGISTER = setup ring buffers
  write() = commit reply                FUSE_IO_URING_CMD_COMMIT_AND_FETCH =
                                        commit previous reply AND fetch next request
  copy_to_user / copy_from_user          Pre-registered userspace ring buffers
  one request per read/write            Combined commit+fetch in one SQE
  syscall per request                   Batch: submit_and_wait

Setup

fuse_uring_create() — allocates fuse_ring with nr_queues = num_possible_cpus(), computes max_payload_sz
fuse_uring_create_queue() — per-CPU queue with 7 lists: ent_avail_queue, ent_w_req_queue, ent_commit_queue, ent_in_userspace, fuse_req_queue, fuse_req_bg_queue, ent_released
fuse_uring_cmd() (the .uring_cmd entry point) dispatches:
- FUSE_IO_URING_CMD_REGISTER → fuse_uring_register(): maps the 2 iovecs from the SQE (headers + payload) into userspace memory, adds to ent_avail_queue. When all queues are ready, switches fiq->ops to fuse_io_uring_ops and marks ring->ready
- FUSE_IO_URING_CMD_COMMIT_AND_FETCH → fuse_uring_commit_fetch(): reads commit_id/qid from the 128-byte SQE, finds the request, commits the reply (copies header+payload from ring), then fetches the next request

Request state machine

Ring entries move through states: FRRS_INVALID → FRRS_COMMIT → FRRS_AVAILABLE → FRRS_FUSE_REQ → FRRS_USERSPACE → (back to AVAILABLE).

Background requests

fuse_uring_queue_bq_req() allows 1 background request per queue independent of global limits, improving throughput for metadata-heavy workloads.

Teardown

fuse_uring_stop_queues() → per-queue teardown via io_uring_cmd_done, with async teardown (FUSE_URING_TEARDOWN_TIMEOUT = 5s) and fuse_uring_destruct().

Citation capsule: FUSE-over-io_uring (dev_uring.c, 1457 lines) replaces /dev/fuse read/write with io_uring shared rings — one queue per CPU. The FUSE_IO_URING_CMD_COMMIT_AND_FETCH operation combines committing the previous reply and fetching the next request in a single SQE, reducing syscall overhead. Enabled via echo 1 > /sys/module/fuse/parameters/enable_uring + FUSE_CAP_OVER_IO_URING (protocol 7.42) (fs/fuse/dev_uring.c).

FUSE_PASSTHROUGH: Bypassing Userspace for Data I/O

passthrough.c (197 lines) + backing.c (~150 lines) implement FUSE_PASSTHROUGH — the biggest performance feature in years.

The big idea

For files with a backing store on a real filesystem, the kernel can perform read/write I/O directly on the backing file, bypassing the userspace daemon entirely. Userspace still handles metadata (lookup, getattr, permission checks), but data I/O skips the round-trip.

How it works

Register backing file. Userspace opens a backing file via the FUSE_DEV_IOC_BACKING_OPEN ioctl on /dev/fuse (handled by fuse_dev_ioctl_backing_open() in dev.c → fuse_backing_open() in backing.c). This registers the file in fc->backing_files_map (an IDR) and returns an integer backing_id.
Pass ID in OPEN reply. Userspace includes the backing_id in the FUSE_OPEN reply.
Resolve at open time. fuse_passthrough_open() (passthrough.c:152) looks up the fuse_backing object via fuse_backing_lookup(), calls backing_file_open() to create a per-open backing file wrapper, and stores it in ff->passthrough.
Delegate I/O. fuse_passthrough_read_iter() → backing_file_read_iter(), fuse_passthrough_write_iter() → backing_file_write_iter(), fuse_passthrough_mmap() → backing_file_mmap(). All delegate to the kernel's backing_file API.

Performance impact

Passthrough eliminates the userspace round-trip for data I/O. For workloads that are primarily data reads/writes (media serving, package management, container images), this can dramatically improve throughput while still letting userspace enforce permissions and implement custom metadata logic.

Writeback Cache (FUSE_WRITEBACK_CACHE)

Without writeback cache, every write() goes to userspace immediately (write-through). With FUSE_CAP_WRITEBACK_CACHE enabled, the kernel buffers writes in the page cache and flushes them later.

Implementation

fuse_inode write cache fields: write_files list, queued_writes, writectr, iocachectr, page_waitq
fuse_cache_write_iter() (file.c:1481): if writeback_cache enabled, uses iomap_file_buffered_write() (write-back mode); otherwise fuse_perform_write() (accumulates folios, sends via fuse_send_write_pages)
fuse_writepages() (file.c:2289): uses iomap_writepages() with fuse_writeback_ops
fuse_sync_bucket: per-connection bucket for synchronizing write completion. fuse_sync_bucket_dec() wakes waiters when the bucket count reaches zero
FUSE_NOWRITE bias: blocks new writes during truncate/fsync

The Control Filesystem (/sys/fs/fuse/connections)

control.c (367 lines) implements the fusectl pseudo-filesystem that exposes per-connection runtime controls at /sys/fs/fuse/connections/<dev>/:

File	Mode	Purpose
`waiting`	0400 (ro)	Number of requests waiting (`fuse_chan_num_waiting`)
`abort`	0200 (wo)	Write to abort all requests (`fuse_chan_abort`)
`max_background`	0600 (rw)	Read/write max background requests (capped by `max_user_bgreq`)
`congestion_threshold`	0600 (rw)	Read/write congestion threshold (capped by `max_user_congthresh`)

fuse_ctl_add_conn() creates the directory + files under fuse_mutex. Non-admin users are capped by the global max_user_* module parameters.

Notifications (Kernel-Side Processing)

notify.c (447 lines) processes unsolicited messages from userspace (written with oh.unique == 0, dispatched from fuse_dev_do_write()). fuse_notify() switches on fuse_notify_code:

Notification	Handler	Action
`FUSE_NOTIFY_POLL`	`fuse_notify_poll()`	Wake up poll waiters
`FUSE_NOTIFY_INVAL_INODE`	`fuse_notify_inval_inode()`	Invalidate page cache for inode range
`FUSE_NOTIFY_INVAL_ENTRY`	`fuse_notify_inval_entry()`	Invalidate dentry cache
`FUSE_NOTIFY_DELETE`	`fuse_notify_delete()`	Invalidate/unlink child entry
`FUSE_NOTIFY_STORE`	`fuse_notify_store()`	Push kernel page-cache data to userspace
`FUSE_NOTIFY_RETRIEVE`	`fuse_retrieve()`	Retrieve data from userspace into page cache
`FUSE_NOTIFY_RESEND`	`fuse_notify_resend()`	Re-queue inflight requests (daemon failover)
`FUSE_NOTIFY_INC_EPOCH`	`fuse_notify_inc_epoch()`	Bump epoch + schedule dentry invalidation
`FUSE_NOTIFY_PRUNE`	`fuse_notify_prune()`	Try-prune inodes (batches of 512)

All handlers hold fc->killsb (read) while looking up inodes, preventing superblock freeing during processing.

Recent Features and Future Directions

The FUSE kernel module is actively developed. Recent additions:

FUSE_PASSTHROUGH — direct kernel-to-backing-file I/O bypassing userspace for data operations (protocol 7.40). The biggest performance feature in years.
FUSE-over-io_uring — io_uring transport for reduced syscall overhead (protocol 7.42)
Request timeouts (req_timeout.c) — fuse_check_timeout() runs every 15s, scans all queues, aborts the connection if any request exceeds req_timeout
Sync FUSE_INIT — SELinux compatibility (process requests during mount handshake)
FUSE_SECURITY_CTX — SELinux/LSM security context passthrough
FUSE_HANDLE_KILLPRIV_V2 — improved privilege handling on write/chown/trunc
DAX (dax.c, ~1500 lines) — direct access to CXL persistent memory
Virtio-fs (virtio_fs.c, ~2000 lines) — FUSE over virtio for virtual machines
famfs — CXL-attached memory filesystem (2024-2025 development, RFC patches)

How to Read the Source: A Map for Newcomers

fuse_i.h — all core data structures (fuse_conn, fuse_inode, fuse_file, fuse_chan)
fuse_dev_i.h — request, channel, queue structures
dev.c — /dev/fuse transport and request lifecycle
inode.c — inode operations, FUSE_INIT, superblock setup
file.c — file operations (read, write, mmap, ioctl)
dir.c — directory operations
dev_uring.c — io_uring transport
passthrough.c — direct I/O bypass
control.c — sysfs control interface
notify.c — kernel-side notification processing

Frequently Asked Questions

What is the relationship between the FUSE kernel module and libfuse?

The kernel module (fs/fuse/) intercepts VFS calls and forwards them to userspace via /dev/fuse. libfuse is the userspace library that reads those requests, dispatches to your filesystem callbacks, and writes responses back. They communicate via the FUSE protocol defined in include/uapi/linux/fuse.h. See our companion post on libfuse internals for the userside perspective.

How many lines of code is the FUSE kernel module?

The fs/fuse/ directory contains ~13,000+ lines across 30+ .c and .h files. The largest files are file.c (3121 lines), dir.c (2498), dev.c (2430), inode.c (2190), dev_uring.c (1457), and virtio_fs.c (~2000 lines).

What is FUSE passthrough?

FUSE_PASSTHROUGH lets the kernel perform read/write I/O directly on a backing file, bypassing the userspace daemon for data operations. Userspace still handles metadata (lookup, getattr). This eliminates the userspace round-trip for data I/O — a significant performance win for data-heavy workloads.

How does FUSE-over-io-uring work?

Instead of read()/write() on /dev/fuse, both kernel and userspace use io_uring shared ring buffers. The FUSE_IO_URING_CMD_COMMIT_AND_FETCH operation combines committing the previous reply and fetching the next request in a single SQE. This reduces syscall overhead and improves throughput for I/O-heavy workloads.

Is the FUSE kernel module actively maintained?

Yes — and this is where the FUSE story gets interesting. The kernel module is actively maintained by Miklos Szeredi (original author) with regular additions: io_uring support, passthrough, request timeouts, DAX, and security context passthrough. But the userspace libfuse library is in limited-maintenance mode (no active regular contributors beyond the maintainer who applies PRs and ships releases). This creates a growing gap: the kernel module keeps gaining features (FUSE_PASSTHROUGH, FUSE_OVER_IO_URING, request timeouts, sync_init, FUSE_HANDLE_KILLPRIV_V2) that libfuse doesn't fully support yet. Developers who need the latest kernel FUSE features may need to interface with the kernel protocol directly or use alternative userspace implementations.

Conclusion

The FUSE kernel module is the gatekeeper between the Linux VFS and userspace filesystems. Its design — a request lifecycle with pending/processing/background queues, a transport abstraction supporting both /dev/fuse and io_uring, and a growing set of features that bypass userspace — makes it one of the most interesting subsystems in the kernel.

The source rewards top-down reading: start with fuse_i.h for the data structures, dev.c for the request lifecycle, then file.c/dir.c/inode.c for the VFS operations, and finally dev_uring.c and passthrough.c for the performance features. Clone the kernel tree, build with FUSE enabled, and trace a read() from VFS through to userspace and back.

Sources

Linux kernel fs/fuse/ source, https://github.com/torvalds/linux/tree/master/fs/fuse
Kernel FUSE documentation, https://www.kernel.org/doc/html/next/filesystems/fuse.html
Kernel fuse-io-uring documentation, https://www.kernel.org/doc/html/next/filesystems/fuse-io-uring.html
libfuse deep dive (companion post), /posts/libfuse-deep-dive-software-engineer/
include/uapi/linux/fuse.h (FUSE protocol header), https://github.com/torvalds/linux/blob/master/include/uapi/linux/fuse.h
